PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength
PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength
PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength
PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength
Specifications
Brand Name :
SZ
Model Number :
SZWZ
Certification :
ISO
Place of Origin :
CHINA
MOQ :
10.000 square meter
Price :
$0.3-$2.0/SQM
Payment Terms :
,L/C,T/T,D/P,D/A,Western Union,MoneyGram
Supply Ability :
2 tons per day
Delivery Time :
5-8 working days
Packaging Details :
Roll with paper coil inside and poly bag outside
Geotextile Type :
Woven Geotextiles
Material :
PP
Feature :
Non-toxic,Eco-friendly,Reusable
Application :
Agricultural Cultivation
Weight :
100-800Gram
Fiber type :
PP flat wire or Twill
Color :
Black,brown,green
Width :
4-6m
Description

High Strength PET Woven Geotextile Road Stabilization Fabric 20 - 1000 KN

Pet Woven Geotextile Fabric is woven geo fabric made from high tenacity, low elongation material of multifilament polyester yarns to form a stable structure. BPM brand pet woven geotextile fabric is woven and blended by individual multifilament yarns woven together into a stable fabric structure with a superior combination of mechanical and hydraulic properties. Our pet woven geotextile fabric series has excellent resistance to biological and chemical environments normally found in soils and are stable against short-term exposure to ultraviolet radiation. The woven geotextile fabric is widely used for reinforcement of embankments, retaining structures, steep slopes, linear constructions, landfills, waste deposits, etc.

Material properties and types

1. Basic materials

·Woven from polyester fiber (Polyester/PET), some products are combined with polypropylene (PP) to enhance performance.

·It is divided into two processes: filament weaving and staple needle punching. Filament products have higher strength, while staple needle punching focuses on filtering performance.

2. Weight and specifications

·Weight range: 100g/m²~1200g/m², common specifications are 200g, 300g, 500g, etc.

·Width: 1m~6m, customizable, single roll length is usually 50~100 meters.

PET WOVEN Geotextile Specification
Property Unit 100-50 300-50 500-50 600-50 1200-50
Ultimate Tensile Strength MD KN/m 100 300 500 600 1200
Ultimate Tensile Strength CD KN/m 50 50 50 50 50
Strain at short term strength % 10 12 12 12 12
Elongation % 30 30 30 30 30
Apparent Opening Size mm 0.15 0.15 0.15 0.15 0.15
UV resistance ( Retained 500 Hours) % 70 70 70 70 70
Width m 5.2 5.2 5.2 5.2 5.2
Height m 100 100 100 100 75
Roll weight Kg 140 320 480 580 810

Main application areas

1. Engineering reinforcement and protection

· Road and railway subgrade reinforcement to prevent soil subsidence and cracks.

· River embankment and reservoir slope protection to resist water erosion.

2. Drainage and filtration

· Laying soil drainage layer to separate sand and clay to prevent blockage.

· Liquid drainage in mines and landfills.

3. Special scenarios

· Groundwater control, ecological slope protection and greening to support vegetation growth.

PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High StrengthPP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength

PP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High StrengthPP PET Woven Geotextile Road Stabilization Fabric 20-1000KN High Strength

Advantages and certification

1. Technical advantages

·Lightweight design, convenient construction, and adaptable to complex terrain.

·Long-term stability and strong anti-deformation ability.

2. Quality certification

·ISO 9001 and ISO 14001 certified, some products meet international engineering standards.
