Specifications
Place of Origin :
Zhejiang, China
Model Number :
SUN-5K-SG03LP1-EU
Brand Name :
Deye
Input Voltage :
220V/380V,230V/400V
Output Voltage :
220V/380V,230V/400V
Output Current :
8A
Output Frequency :
50Hz/45Hz-55Hz 60Hz/55Hz-65Hz, 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
Output Type :
Three Phase, Three-Phase Grid
Size :
408x638x237mm
Type :
DC/AC Inverters
Inverter Efficiency :
99%
Weight :
30.5KG
Product name :
Deye inverter
Application :
Home/Commercial/Industrial
Inverter type :
Hybrid Grid Inverter
Warranty :
5 Years
Keyword :
Solar Energy Power Inverter
Battery type :
Lead Acid / Lithium / Gel
Display :
LCD Display
Certificate :
IEC/EN,IEC/EN 62109-1, IEC/EN 62109-2
MOQ :
1 set
Price :
$871-891 / set
Description

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home

What is Hybrid Inverter?
Hybrid Solar Energy System Also Named On&Off Grid Solar Energy System. With the feature and function of both on grid and off grid solar energy systems. If you have a set of hybrid solar energy system, you could use electricity from solar panels in the daytime when is sunny, you could use electricity stored in a battery bank in the evening or on rainy days,and you also can sell extra electricity to the grid.

Product Description

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home

Product Parameter

Model SUN-5K-SG01HP3-EU-AM2 SUN-6K-SG01HP3-EU-AM2 SUN-8K-SG01HP3-EU-AM2 SUN-10K-SG01HP3-EU-AM2 SUN-12K-SG01HP3-EU-AM2 SUN-15K-SG01HP3-EU-AM2
Battery Input Data
Battery Type Lithium Ion
Battery Voltage Range(V) 160V-700V
Max. Charging Currect(A) 30 30
Max. Discharging Currect(A) 37 37
Charging Strategy for li-ion Battery Self-adaption to BMS
PV String Input Data
Max. PV Input Power(W) 650 7800 10400 13000 15600 19500
Max. PV Input Voltage Power(V) 1000
Start-up Voltage(V) 180
MPPT Voltage Range(V) 150-850
Rated PV Input Voltage(V) 600
Max. Operating PV Input Currect(A) 20+20 26+20
Max. Input Short-Circurt Currect(A) 20+20 39+30
NO. of MPP Trackers/NO. of Strings per MPP Tracker 2/1+1 2/2+1
AC Input/Output Data
Rated AC Input/Output Active Power(W) 5000 6000 8000 10000 12000 15000
Max. AC Input/Output Apparent Power(VA) 5500 6600 8800 11000 13200 16500
Rated AC Input/Output Power(A) 7.6/7.3 9.1/9.6 13.4/12.8 15.2/14.5 18.2/17.4 22.8/21.8
Max. AC Input/Output Power(A) 8.4/8 10/9.6 13.4/12.8 16.7/16 20/19.2 25/24
Max. Continuous AC Passthrough(grid to load)(A) 40 80
Peak Power(off-grid)(W) 1.5 times of rated power,10s
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range(V) 220/380V,230V/400V, 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range(Hz) 50/45-55,60/55-65
Grid Connection Form 3L+N+PE
Total Currect Harmonic DIstortion THDi <3%(of nominal power)
DC Injection Currect <0.5%ln
Efficiency
Max. Efficiency 97.6%
Euro Efficiency 97%
MPPT Efficiency >99%
Equipment Protection
Integrated DC Polarity Reverse Connection Protection,AC Output Overcurrect Protection,AC Output Overvoltage Protection,AC Output Short Circuit Protection,Thermal Protection,DC Terminal Insulation Impedance Monitoring,DC Component Monitoring,Ground Fault Currect Monitoring,Power Network Monitoring,Island Protection Monitoring,Earth Fault Detection,DC Input Switch Overvoltage Load Drop Protection,Residual Currect(RCD) Detection,Surge Protection Level
Surge Protection Level TYPE II(DC), TYPE II(AC)
Interface
Communication Interface RS232/RS485/CAN
Monitor Mode GPRS/WIFI/Bluetooth/4G/LAN(optional)
General Data
Operating Temperature Range(℃) -40℃ to 60℃,>45℃ Derating
Permissible Ambinet Humidity 0-100%
Permissible Altitude 2000m
Noise (nB) <55
Ingress Protection(IP) Rating IP65
Inverter Topology Non-Isolated
Over Voltage Category OVC II(DC),OVC III(AC)
Cabinet Size(WxHxD mm) 408x638x237(Excluding Connectors and Brackets)
Weight(KG) 30.5
Type of Cooling Natural Cooling Intelligent Air Cooling
Warranty 5 Years/10 Years,the Warranty Period Depends the Final Installation Site of Inverter,More Info Please Refer to Deye Warranty Policy
Grid Regulation VDE4105,IEC61727/62116,VDE0126,AS4777.2,CEI0 21,EN50549-1,G98,G99,C10-11,UNE217002,NBR16149/NBR16150
Safety/EMC Standard IEC/EN61000-6-1/2/3/4,IEC/EN 62109-1,IEC/EN 62109-2
Welcome to Contact us by WhatsApp/WeChat:+86 195 2497 2827

Company Information

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home
Projects & Feedback

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home

Packaging & Shipping

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home
Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home
Certifications

Efficient and Reliable Energy Use Deye 5KW Hybrid System 3 Phase High Voltage Solar Inverter for Home







FAQ



Q: Are you a trading company or manufacturer?
A: We are an original factory with more than 11 years of experience.

Q: Do you provide after-sales service?
A: Yes, the warranty is 5 years, if there's any quality problem during the warranty period, we can send new components as replacement.

Q: Can I order samples to test?
A: Yes, we can sell samples to you.

Q: How long for lead time?
Samples are 3-5 days and bulk order is 7-15 days.

Q: Is your battery with real capacity?
A: All of our battery cells with Grade A 100% new, and have real capacity.

Q: What kind of certificates do you have?
A: ISO, CE, FCC, IEC62133, MSDS, UN38.3, etc.

Q: What is your term of payment?
A: We accept T/T, PayPal, Western Union, and so on.
