Specifications
Place of Origin :
Guangdong, China
Model Number :
SUN-20K-SG05LP3 -EU-SM2
Brand Name :
Deye
Input Voltage :
180V~1000V
Output Voltage :
230/400V
Output Current :
7.3A-39.9A
Output Frequency :
50Hz/60Hz
Output Type :
Three Phase
Size :
422W*699.3H*279D
Type :
DC/AC Inverters
Inverter Efficiency :
97.60%
Weight :
25-48kg
Product name :
Deye hybrid solar inverter
Feature :
Single / Three Phase | LV Battery Supported
48V Hybrid Inverter :
SUN-5K-SG04LP3-EU SUN-6K-SG04LP3-EU
SUN-8K-SG04LP3-EU :
SUN-10K-SG04LP3-EU SUN-12K-SG04LP3-EU
Deye 5kW three Phase Inverter :
SUN-5K-SG04LP3-EU
Deye 6kW 3-Phase Hybrid Inverter :
SUN-6K-SG04LP3-EU
Deye 8kW 3-P Hybrid Inverter :
SUN-8K-SG04LP3-EU
Deye 10kW 3-Phase Hybrid Inverter :
SUN-10K-SG04LP3-EU
Deye 12kW Three Phase Hybrid Inverter :
SUN-12K-SG04LP3-EU
Deye 20kW Three Phase Hybrid Inverter :
SUN-14K/15k/16K/18K/20k-SG05LP3-EU-SM2
MOQ :
1 piece
Price :
$2,618-2,688 / piece
Description
Product Description

Deye SUN-20K-SG05LP3 -EU-SM2 Three Phase Low Voltage LiFePO4 Battery 20KW Deye Hybrid Inverter
Deye SUN-20K-SG05LP3 -EU-SM2 Three Phase Low Voltage LiFePO4 Battery 20KW Deye Hybrid Inverter
Deye SUN-20K-SG05LP3 -EU-SM2 Three Phase Low Voltage LiFePO4 Battery 20KW Deye Hybrid Inverter
Model SUN-10K-SG04LP3-EU SUN-12K-SG04LP3-EU SUN-14K-SG05LP3-EU-SM2 SUN-15K-SG05LP3-EU-SM2 SUN-16K-SG05LP3-EU-SM2 SUN-18K-SG05LP3-EU-SM2 SUN-20K-SG05LP3-EU-SM2
Battery Input Data
Battery Type Lithium Ion/Lead-acid
Battery Voltage Range(V) 40-60
Max. Charging Currect(A) 210 240 260 280 300 330 350
Max. Discharging Currect(A) 210 240 260 280 300 330 350
Charging Strategy for li-ion Battery Self-adaption to BMS
PV String Input Data
Max. PV Access Power(W) 20000 24000 28000 30000 32000 36000 40000
Max. PV Input Power(W) 13000 15600 22400 24000 25600 28800 32000
Max. PV Input Voltage Power(V) 800
Start-up Voltage(V) 160
MPPT Voltage Range(V) 200-650 160-650
Rated PV Input Voltage(V) 550
Max. Operating PV Input Currect(A) 26+13 36+36
Max. Input Short-Circurt Currect(A) 34+17 54+54
NO. of MPP Trackers/NO. of Strings per MPP Tracker 2/2+1 2/2+1
AC Input/Output Data
Rated AC Input/Output Active Power(W) 10000 12000 14000 15000 16000 18000 20000
Max. AC Input/Output Apparent Power(VA) 11000 13200 15400 16500 17600 19800 22000
Rated AC Input/Output Power(A) 15.2/14.5 18.2/17.4 21.3/20.3 22.8/21.8 24.3/23.2 27.3/26.1 30.4/29
Max. AC Input/Output Power(A) 16.7/15.9 20/19.1 23.4/22.4 25/24 26.7/25.6 30/28.7 33.4/31.9
Max. Continuous AC Passthrough(grid to load)(A) 45 70
Peak Power(off-grid)(W) 2 times of rated power,10s
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range(V) 220/380V,230V/400V, 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range(Hz) 50/45-55,60/55-65
Grid Connection Form 3L+N+PE
Total Currect Harmonic DIstortion THDi <3%(of nominal power)
DC Injection Currect <0.5%ln
Efficiency
Max. Efficiency 97.6%
Euro Efficiency 96.5%
MPPT Efficiency >99%
Equipment Protection
Surge Protection Level TYPE II(DC), TYPE II(AC)
Interface
Communication Interface RS232/RS485/CAN
Monitor Mode GPRS/WIFI/Bluetooth/4G/LAN(optional)
General Data
Operating Temperature Range(℃) -40℃ to 60℃,>45℃ Derating
Permissible Ambinet Humidity 0-100%
Permissible Altitude 2000m
Noise (nB) <55
Ingress Protection(IP) Rating IP65
Inverter Topology Non-Isolated
Over Voltage Category OVC II(DC),OVC III(AC)
Cabinet Size(WxHxD mm) 422x658x254(Excluding Connectors and Brackets) 456x750x268.5(Excluding Connectors and Brackets)
Weight(KG) 38 50.6
