120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
Specifications
Place of Origin :
Guangdong, China
Model Number :
SPH 10000TL-HU-US
Brand Name :
Growatt
Input Voltage :
240V
Output Voltage :
120V/208V, 120V/240V Split (180Vac - 280Vac)
Output Current :
50A
Output Frequency :
50/60Hz
Output Type :
Single, DUAL Camera
Size :
400x638x187mm
Type :
DC/AC Inverters
Inverter Efficiency :
97.5%
Weight :
48.84kg
Nominal AC input power :
1000W
Nominal input voltage :
240V
Nominal input current :
41.67A
Max. generator input power :
10000W
Nominal AC voltage(range*) :
120V/ 208V, 120V/240V Split (180V-280V)
Battery voltage range :
40V-60V
Max stackable number :
6
THDi :
<3%
Product name :
Growatt Hybrid Inverter
Application :
Solar Energy Storage
MOQ :
1 piece
Price :
$1,918-1,968 / piece
Description
Product Description
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
Specification
Specification
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter

SPH 10000TTLL-HU-US

·* UPS function, 10ms transition
* 1.5 DC/AC Ratio with 3 Mppts
* Up to 200A charging/discharging current
* Support DC-coupled, AC-coupled, AC-retrofit applications
* Type II Surge protection for DC and AC sides
* Support charge from diesel generator
* Support up to 6 units in parallel
* Support form a 220V or 208V three-phase system
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
Datasheet
SPH 10000TL- HU-US
Input data (DC)
Max. recommended PV power (for module STC)
15000W
Max. DC voltage
525V
Start voltage
150V
MPP voltage range
150V-450V/370V
No. of MPP trackers
3
No. of PV strings per MPP tracker
2
Max. input current per MPP tracker
22A
Max. short-circuit current per MPP tracker
27A
Output data (AC)
AC nominal power
10000W
Max. AC apparent power
10000VA
Nominal AC voltage (range*)
120V/208V, 120V/240V Split (180Vac - 280Vac)
AC grid frequency (range*)
50Hz/60Hz
Max. output current
50A
Adjustable power factor
0.8leading…0.8lagging
THDi
<3%
AC grid connection type
Single phase
Battery data (DC)
Battery voltage range
40~60V
Max charging and discharging current
200A
Continuous charging and discharging power
10000W
Type of battery
Lithium /Lead-acid
Backup power (AC)
AC nominal output power
10000W
Nominal AC output voltage
220V/230V/240V
Nominal AC output frequency
50/60Hz
Switch time
<10ms
Efficiency
peak. efficiency
97.50%
CEC welghted efficiency
97%
MPPT efficiency
≥99.5%
Protection devices
PV Switch
Yes
AC over current protection
Yes
AC over voltage protection
Yes
Ground fault monitoring
Yes
Grid monitoring
Yes
Anti-islanding protection
Yes
Residual-current monitoring unit
Yes
Insulation resistance monitoring
Yes
AFCI Protection
Yes
Surge protection
DC Type II / AC Type II
General data
Dimensions (W / H / D)
440×855×256mm
Weight
48.84kg
Operating temperature range
–25°C ... +60°C with derating above 45°C
Noise emission (typical)
≤ 30 dB(A)
Self-Consumption <
< 60 W
Topology
Tranformerless
Cooling
Smart cooling
Protection degree
IP65
Relative humidity
0~100%
Altitude
2000m
DC connection
Quick Connector
Display
LCD
Interfaces: RS485/CAN/USB
Yes
Communication
WIFI/4G cellular (Opt)
Warranty(5/10 years)
Yes/Opt
Project Cases

120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
Packaging & Shipping

120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
120V 208V 240V Growatt SPH 10000TL-HU-US 6KW 8KW 10KW 12KW 15KW Deye Split Phase Hybrid Solar PV Inverter
