Specifications
Battery Type :
LiFePO4
Model Number :
LFP48-200
Brand Name :
Deye
Place of Origin :
Zhejiang, China
System Voltage :
51.2 V
Output Power Range :
10~20 kWh
Dimension (L*W*H) :
600*750*200mm
Weight :
99KG
System Type :
Wall-Mounted
Type :
Lifepo4
Communication Port :
CAN, Rs485
Protection Class :
IP20
Grid connection :
Off grid, Hybrid grid
Product name :
LFP Battery for home use
Cycle Life: :
6000Cycles
Material: :
Lithium Iron Phosphate Battery
Weight with package :
Approx: 99kg
Application: :
Solar, Wind, UPS, EPS, Home and so on
Certification: :
UN38.3, IEC62619, CE,UK VDE2510 50, CEI 0 21, FCC
OEM/ODM: :
Acceptable
Warranty :
10 Years
MOQ :
1 unit
Price :
$1,299-1,419 / unit
Description
Product Description
DEYE 208AH 10.6KWH Home Energy Storage 51.2V Power Wall Deye RW-F10.6 Wall-Mounted LFP Battery for Home Use
DEYE 208AH 10.6KWH Home Energy Storage 51.2V Power Wall Deye RW-F10.6 Wall-Mounted LFP Battery for Home Use
Safer
Cobalt Free Lithium Iron Phosphate (LFP) Battery, safety and long lifespan and high-energy density. Low Voltage safety connection.

Convenient
Battery module auto networking(No DIP switch code), easy maintenance, support Deye remotely monitoring and upgrade.

Eco-Friendly
Use environmental protection materials, the whole module non-toxic, pollution-free.



Flexible
Modular design, easy to expand, Max. 32 units in parallel, Max. capacity of 340kWh. Suited to residential and commercial
applications for increasing the self-consumption ratio.


Two Mounting Methods
Flat design, Wall-mounted with Wall Bracket, Floor Stand with removable base, saving installation space.


DEYE 208AH 10.6KWH Home Energy Storage 51.2V Power Wall Deye RW-F10.6 Wall-Mounted LFP Battery for Home Use
DEYE 208AH 10.6KWH Home Energy Storage 51.2V Power Wall Deye RW-F10.6 Wall-Mounted LFP Battery for Home Use


High Performance
Maximum support 1C charge and 1.2C discharge. Maximum 6000 cycles at 90% DOD, and 10 years standard warranty.

Reliable
Intelligent BMS, providing complete protection. Natural cooling, IP20, wide temperature range: -20°C to 55°C.
Specification
Main Parameter
Battery Chemistry
LiFePO4
Capacity (Ah)
208
Scalability
Max. 32 pcs pack (Max.340kWh) in parallel
Nominal Voltage (V)
51.2
Operating Voltage(V)
43.2~57.6
Energy (kWh)
10.64
Usable Energy (kWh)
9.58

Charge/Discharge Current (A)
Recommend
104
Max.
Discharge: 250 / Charge: 200
Peak
300 (2mins, 25°C)
Other Parameter
Recommend Depth of Discharge
90%
Dimension (W/H/D, mm)
600*750*200(Without hanging board)
Weight Approximate(kg)
99
Master LED Indicator
LED(SOC:20%~SOC100% and working state)
IP Rating of Enclosure
IP20
Operating Temperature
Charge: 0~55℃(Optional heating)
Discharge: -20℃~55℃
Storage Temperature
15℃~35℃
Humidity
5%~95%
Altitude
≤2000m
Cycle Life
≥6000(25℃±2℃,0.3C/0.3C, 90% DOD, 70% EOL)
Installation
Wall-Mounted, Floor-Mounted
Communication Port
CAN2.0, RS485
Cycle Life
≥6000(25°C±2°C,0.5C/0.5C,90%DOD,70%EOL)
DEYE 208AH 10.6KWH Home Energy Storage 51.2V Power Wall Deye RW-F10.6 Wall-Mounted LFP Battery for Home Use
