Specifications
Brand Name :
Syscode
Model Number :
F200
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
1299$~15999$
Payment Terms :
L/C,T/T
Delivery Time :
2-3 work days
Packaging Details :
Carton Box
Marking Content :
Text, graphics, barcodes, QR codes, dynamic serial numbers, real-time clock, TXT files, RS232 communication data, etc.
Marking Angle :
Any angle, four-dimensional adjustable
Operating Language :
Chinese, English (supports other languages)
Protection Level :
≥ IP54
Cooling :
Air Cooling
Max Linear Marking Speed :
10,000 mm/s
Output Power :
30W / 50W / 100W
Focal Length :
210mm (standard field lens range 110 x 110)
Laser Type :
Fiber Laser Wavelength: 1064nm, meets 100,000 hours of operation
Humidity :
Relative Humidity 80% RH, non-condensing
Description

Metal & Plastic Product Marking Tool: A Guide to Industry Applications of Fiber Laser Coding Machines

Fiber laser coding machines are devices that use fiber laser technology for marking and coding. They have several notable features:

  • High Precision: Fiber laser coding machines can achieve high-precision markings, suitable for small text and complex patterns.

  • Fast Speed: These machines operate at high speeds, meeting the demands of large-scale production.

  • Wide Material Compatibility: They can code on various materials such as metal, plastic, glass, and wood, making them highly adaptable.

  • Low Maintenance Costs: Fiber lasers have a long lifespan, resulting in relatively low maintenance costs and reducing long-term operational expenses for businesses.

  • Environmentally Friendly: Laser coding technology does not use ink, reducing the use of chemicals and being more environmentally friendly.

These features make fiber laser coding machines widely used in industries such as food, pharmaceuticals, electronics, and automotive.
IP54 Fiber Laser Marking Machine Any Angle 100W Low Maintenance Environmentally Friendly

The printing content is rich and suitable for various materials.


Printing types: Text, numbers, barcodes, QR codes, photos, patterns, production dates, production batch numbers, etc.
Printing materials: Textiles, thin ceramic sheets, single crystal silicon wafers, IC chips, sapphire, polymer films, and other materials.

System Technical Specifications
Technical Specifications of the Syscode F200 Series Laser Marking Machine
Specification Details
Laser Type Fiber Laser Wavelength: 1064nm, meets 100,000 hours of operation
Output Power 30W / 50W / 100W
Focal Length 210mm (standard field lens range 110 x 110)
Max Linear Marking Speed 10,000 mm/s
Marking Parameters
Marking Area 110mm x 110mm, max marking area: 550mm x 550mm
Lines of Marking Any number of lines can be set within the effective marking area
Minimum Line Width 0.02mm
Production Line Speed Up to 150 meters/minute (dependent on marking content)
Character Height 0.2 - 70mm
Fonts Single-line fonts, dot matrix fonts, TrueType fonts
Marking Content Text, graphics, barcodes, QR codes, dynamic serial numbers, real-time clock, TXT files, RS232 communication data, etc.
Marking Angle Any angle, four-dimensional adjustable
Operating Interface
Display Industrial-grade touchscreen
Operating Language Chinese, English (supports other languages)

Working Environment Requirements
Environmental Requirements
Protection Level ≥ IP54
Cooling Air Cooling
Ambient Temperature -5 to 45 degrees Celsius
Humidity Relative Humidity 80% RH, non-condensing
Power Supply 220V, 0.6KVA

Portable Flying Inkjet Printer



This inkjet printer features an innovative design and a unique structure, providing a user-friendly interface. Its high modulation frequency ensures rapid printing, with excellent precision and stable performance, making it highly functional. The product is independently developed and can be customized, modified, and expanded based on customer requirements.
IP54 Fiber Laser Marking Machine Any Angle 100W Low Maintenance Environmentally Friendly
IP54 Fiber Laser Marking Machine Any Angle 100W Low Maintenance Environmentally Friendly

Our Services


1. Free Pre-Sales Consultation

  • Quick Response: We provide pre-sales consultation within 12 hours to address any technical support needs you may have.
  • Solution Design: Tailored advanced solutions for all distributors and users.

2. Services During Sales

  • Quality Assurance: All machines undergo strict quality control checks and testing before shipment.
  • User-Friendly Documentation: Easy-to-understand manuals and operating guides to ensure smooth usage of the equipment.

3. After-Sales Service

  • Free Video Training: Comprehensive free video training to help you get started quickly.
  • Technical Support: Our technicians provide support via English, video calls, and remote control.

4. Special Design and Customization

  • Personalized Service: We are happy to meet your special requirements through innovative design. Whether you need customized machines or OEM orders, please feel free to contact us.
