Corundum Furnace for Smelting White Fused Alumina, Brown Fused Alumina, Dense Alumina & Zirconia Alumina
Corundum Furnace for Smelting White Fused Alumina, Brown Fused Alumina, Dense Alumina & Zirconia Alumina
Corundum Furnace for Smelting White Fused Alumina, Brown Fused Alumina, Dense Alumina & Zirconia Alumina
Corundum Furnace for Smelting White Fused Alumina, Brown Fused Alumina, Dense Alumina & Zirconia Alumina
Specifications
Brand Name :
Shaanxi Chengda
Model Number :
Negotiate based on equipment processing capacity
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 unit
Price :
The price will be negotiated based on the technical requirements and supply scope of Party A
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
Complete production supply chain, supply on time, and meet quality standards
Delivery Time :
2~3 months
Packaging Details :
Discuss according to the specific requirements of Party A
Description

  1. High-Temperature Capability

    • Operates at 2000°C+ to melt ultra-hard abrasives and refractories.

    • Ideal for producing white fused alumina (WFA), brown fused alumina (BFA), dense fused alumina (DFA), and zirconia corundum (AZS).

  2. Advanced Applications

    • Abrasives: Manufacture grinding wheels, sandpapers, and precision polishing compounds.

    • Refractories: Produce high-purity linings for kilns, furnaces, and ladles.

    • Specialty Ceramics: Synthesize zirconia-toughened alumina (ZTA) for extreme environments.

  3. Furnace Technology

    • Arc/Submerged Arc Design: Ensures energy-efficient melting with precise temperature control.

    • Cooling System: Prevents thermal stress in crucibles/lining for extended lifespan.

  4. Material Properties Achieved

    • White Fused Alumina: ≥99% Al2O3, high hardness (Mohs 9).

    • Zirconia Corundum (AZS): 10-40% ZrO2, superior corrosion/thermal shock resistance.

  5. Specification

    1. Inner diameter of furnace shell: Φ 2500mm;

    2. Furnace shell depth: 2000mm;

    3. Straight tube height: 1250mm

    4. Cone height: 750mm

    5. Electrode diameter: Φ 200mm;

    6. Diameter of electrode distribution circle: Φ 650mm;

    7. Electrode stroke: 1700mm;

    8. Electrode lifting speed: 2-2.5m/min;

    9. Rated capacity of transformer: 1000KVA;(Long term overload 20%, short-term overload 30%)

    10. Primary voltage of transformer: 22KV;

    Secondary voltage: 90~150V (seven levels) no-load electric voltage regulation;

    90~130 constant current;130~150V constant power

    Primary current: 26.275A;

    Secondary current: 4446 A (130V);

    Cooling method: OFWF (strong oil water cooling);


    Key attributes


    video outgoing-inspection
    Provided
    key selling points
    High Safety Level
    type
    Arc Furnace
    core components
    PLC
    usage
    Melting Furnace
    machinery test report
    Provided
    warranty
    1 Year
    voltage
    10-35kv
    weight (t)
    20
    place of origin
    Shaanxi, China
    brand name
    HAN
    dimension(l*w*h)
    6*6*7m
    Inner diameter of furnace shell
    2500mm
    Furnace shell depth
    2000mm
    Capacity
    1ton- 20ton
    Material fro furnace smelting
    White Fused Alumina Zirconia Corundum

    Packaging and delivery

    Selling Units
    Single item
    Single package size
    100X100X100 cm
    Single gross weight
    100.000 kg
