Acrylic Glass Sliding Gate Turnstile Full Height Automatic Access Control Subway
Acrylic Glass Sliding Gate Turnstile Full Height Automatic Access Control Subway
Specifications
Brand Name :
KOMAI
Model Number :
KM-SL003
Certification :
ISO, Rohs, CE, FCC
Place of Origin :
China
Protection Level :
IP66
Communication Interface :
Rs485, TCP/IP, RS-232
Barrier motor :
Brushless Motor
Access contol type :
QR Code, IC Card, RFID Card, Fingerprint, Face Recognition, ESD System
Material :
Aluminium Alloy, Stainless Steel, Acrylic Glass
Application :
Airport Office School Park Supermark Subway
Power supply :
AC220V/110V
Working environment :
-10℃~+50℃
Keyword :
Full height Speed Sliding Turnstile
Description

Acrylic Glass Sliding Gate Turnstile Full Height Automatic Access Control Subway

Acrylic Glass Sliding Gate Turnstile Full Height Automatic Access Control Subway

Product Description

Sliding Turnstile

Intellgient sliding turnstile is the intelligent access management produced by our company after several years R & D , this equipment organically integrate machinery electronics microprocessor control,and all kinds of different reading and writing equipment. Through figuring all kinds of different reading and writing equipment,and adopting reliable performance safety protection devices real-time alarm system, and direction indicator interface, realizing the access intelligent control and management by the mutual coordination.
PRODUCT SPECIFICATION
Case Material
SS304(1.5mm, 2.0mm optional)/Baking varnish
Production Process
CNC Laser Cutting
Size
1200*330*980mm(Customization acceptable)
Power input
AC100-240V,50/60HZ
Operation voltage
DC24V, 3A, Power: 40W( Brushless Motor Optional)
Electromagentic
Duty Cycle 100%
Passage Width
550mm
Flap Size
300*1200mm(Customization acceptable for heigth)
Flap Material
Acrylic
Passage direction
Single directional/Bi-directional(Optional)
Operating time
1S
Throughput Rate
30-40 persons/minute(Normally Closed) or 40 persons/(Normally Open)
Reset Time after Power on
3S
MCBF
5,000,000 Cycles
Reset Time after failure
10S
Automatic Reset Function
Automatically locked within set time(Time Adjustable)
Operation Humidity
0~90%(No Freezing)
Operation Temperature
-10℃~+50℃
Operation Eenvironment
Indoor,Outdoor(Shelter)
Protection Level
IP45
Communication Interface
Standard RS485 interface, distance ≤1200 meters
Input Interface
Relay switch signal or 12V electrical level signal or 12V pulse signal of pulse width > 100ms, drive current >10mA
