Specifications
Brand Name :
NORGREN
Model Number :
M/31123
Certification :
ISO/TS16949:2009
Place of Origin :
UK
MOQ :
5pcs
Price :
USD189.9-229.9/PC
Payment Terms :
L/C,T/T, Or Others
Supply Ability :
1000 PCS/Week
Delivery Time :
3-7 Working Days
Packaging Details :
Strong Carton Box or as Customers Requirement
Model Name :
Rubber Air Spring
Material :
Rubber and Steel
Warranty :
12 Months
Other Name :
Rubber Air Bellows
MOQ :
4PCS
NORGREN :
M/31123
Port Size :
G1/2
Stroke length :
330mm
Description
M/31123 Original Norgren Rubber Air Spring FT 412-32 DS Contitech Spring Bag Air Navigator
Product Description
Item Name Rubber Air Spring
Model No. M/31123
Brand NORGREN
Warranty 12 Months
Type Convoluted Air Spring
Service Offered OEM
Suspension System Air Spring Suspension
Applications For Car Suspension
Material Imported Natural Rubber
Operation Gas-filled
Package Standard Packing Or Customized
Interchange Numbers

Original NORGREN Numbers:

  • M/31123
  • M 31123
  • M31123
  • 12X3

FIRESTONE Numbers:

  • W01R584062
  • W01 R58 4062
  • W01-R58-4062
  • WO1R584062
  • WO1 R58 4062
  • WO1-R58-4062
  • FIRESTONE Bellows Number: 12''X3
  • FIRESTONE Bellows Number: 12X3

Other Manufacturer Numbers:

  • DUNLOP Number: SP1542
  • CONTITECH Number: FT412-32
  • CONTITECH Number: FT 412-32
  • CONTITECH Number: FT412-32 DS
  • CONTITECH Number: FT 412-32 DS
M/31123 Rubber Air Spring Technical Data
Model M/31061 M/31062 M/31081 M/31082 M/31101 M/31102 M/31103 M/31121 M/31122
Cylinder∅(inch) 6'' 6'' 8'' 8'' 10'' 10'' 10'' 12'' 12''
Port Size G1/2 G1/2 G1/2 G1/2 G1/2 G1/2 G1/2 G1/2 G1/2
Convolutions 6''x1 6''x2 8''x1 8''x2 10''x1 10''x2 10''x3 12''x1 12''x2
Stroke(mm) 55 115 75 175 100 225 330 100 225
Installation height min(mm) 50 75 50 75 50 75 100 50 75
Recomended max working height(mm) 95 170 115 220 135 245 350 135 245
Installation height max(mm) 105 190 130 250 150 300 430 150 300
Retracting force to rech min height(N) 140 220 220 350 150 150 250 200 250
Model M/31123 M/31141 M/31142 M/31143 M/31162 M/31163 M/32212 M/32262
Cylinder∅(inch) 12'' 14 1/2'' 14 1/2'' 14 1/2'' 16'' 16'' 21'' 26''
Port Size G1/2 G1/2 G1/2 G1/2 G1/2 G1/2 - -
Convolutions 12''X3 14 1/2''X1 14 1/2''X2 14 1/2''X3 16''X2 16''X3 21''x2 26''x2
Stroke(mm) 300 100 265 380 315 430 251 400
Installation height min(mm) 100 50 75 100 75 120 84 100
Recomended max working height(mm) 350 135 290 420 350 475 284 425
Installation height max(mm) 430 150 340 480 390 550 335 500
Retracting force to rech min height(N) 250 200 280 330 250 100 311 400
M/31123 Original Norgren Rubber Air Spring FT 412-32 DS Contitech Spring Bag Air Navigator M/31123 Original Norgren Rubber Air Spring FT 412-32 DS Contitech Spring Bag Air Navigator
