Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
Specifications
Brand Name :
GUOMAT
Model Number :
6X2
Certification :
ISO/TS16949:2009
Place of Origin :
GuangDong, China
MOQ :
6pcs
Price :
$59.9-69.9/pc
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
Strong Carton Box Or As Customers Need
Material :
Natural Rubber+Steel
Warranty :
1 Year
Gas Hole :
G1/2
Min. Pressure :
0 bar
Color :
Black
Package :
Neutral Brown Carton Packaging
Cross Number :
FD76-14 DS CR
Function :
Shock Absorption
Description

Contitech FD76-14 Packaging Machinery Suspension Air Spring G1/2 Rubber Air Bellows China

Product Description

FIRESTONE W01R584053

FIRESTONE W01-R58-4053

FIRESTONE W01 R58 4053

FIRESTONE Part Number w01r584063

FIRESTONE Part Number w01 r58 4063

FIRESTONE Part Number w01-r58-4063

DUNLOP SPRINGRIDE SP1482

DUNLOP SPRINGRIDE SP 1482

DUNLOP PNEURIDE 6X2(Steel)

DUNLOP PNEURIDE 6''X2

CONTITECH FD 76-14 DS CR

CONTITECH FD 76-14 DS M10

CONTITECH FD 76-14 DS M10 G1/2

CONTITECH FD 76-14 M10 G1/2

CONTITECH FD 76-14 M10 G1/2 DS

CONTITECH FD 76-14 M10 G1/2 DS CR

CONTITECH FD 76-14 / FD76-14 FD76 14

NORGREN M/31062

NORGREN M 31062

NORGREN M31062

PARKER 9109001

PARKER 910 900 1

FD 76-14 DS CR Double Convolution Air Actuator Technical Data

Top Cover Plate Diameter (Width): Ø153.5 mm

Bottom Cover Plate Diameter (Width): Ø153.5 mm

Material top and bottom plate:Aluminium

Gas Hole / Air Inlet : G1/2

Top Cover Plate Screw (Nut) Tooth : 4 X M8

Bottom Cover Plate Screw (Nut) Tooth : 4 X M8

Rubber Bellows Diameter : Max Ø178 mm

The Working Stroke : 75 mm - 190 mm

With Girdle Hoop :One Pieces of Girdle Hoop

Type

Firestone

Dunlop Pneuride

Dunlop Springride

Contitech

Norgren

Parker

4 1/2" x 1

W01R584050

4 1/2" x 1

SP2334

FS 44-5 DI

PM/31041

9109400

4 1/2" x 2

W01R584051

4 1/2" x 2

SP2441

FD 44-10 DI

PM/31042

9109401

4 1/2" x 3-E

W01R584035

4 1/2" x 3

SP2895

FT 44-15 DI

PM/31043

9109402

6" x 1

W01R584078

6" x 1

SP2913

FS 76-7 DI

PM/31061

9109004A

6" x 1

W01R584052

6" x 1

SP1536

FS 76-7 DS

M/31061

9109004

6" x 2

W01R584070

6" x 2

SP2917

FD 76-14 DI

PM/31062

9109001A

6" x 2

W01R584053

6" x 2

SP1482

FD 76-14 DS

M/31062

9109001

6" x 3

6" x 3

SP2923

FT 76-20 DI

PM/31063

9109007A

6" x 3

W01R584095

6" x 3

SP2861

FT 76-20 DS

M/31063

9109007

8" x 1

W01R584054

8" x 1

SP1537

FS 138-8 DS

M/31081

9109014

8" x 2

W01R584055

8" x 2

SP1490

FD 138-18 DS

M/31082

9109011

8" x 3

W01R584056

8" x 3

SP2863

FT 138-26 DS

M/31083

9109017

10" x 1

W01R584057

10" x 1

SP2523

FS 210-10 DS

M/31101

9109024

10" x 2

W01R584058

10" x 2

SP1538

FD 210-22 DS

M/31102

9109021

10" x 3

W01R584059

10" x 3

SP1539

FT 210-32 DS

M/31103

9109031

Real Picture

Contitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air BellowsContitech FD76-14 Industrial Air Spring For Packaging Machinery Suspension G1/2 Rubber Air Bellows
