W01-358-7009 Air Spring Actuator 1B12-301 For SAF Holland 90557002
W01-358-7009 Air Spring Actuator 1B12-301 For SAF Holland 90557002
Specifications
Brand Name :
GUOMAT
Model Number :
1B5330D
Certification :
ISO/TS16949:2009
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T, Western Union,Paypal or Others
Supply Ability :
1000pcs/week
Delivery Time :
2-8 work days
Packaging Details :
strong carton box or as customers need
Material :
Rubber Steel
Firestone :
W01-358-7009
Warranty :
1 Year
Weight :
4.8 kg
Other names :
Air Vibration shock absorbers
Pressure Ability :
0.2-0.8 M Pa
SAF Holland :
90557002
Contitech :
FS 330-11 468
Description

W01-358-7009 Firestone Air Spring actuator Air Lift Bags 1B12-301 For SAF Holland 90557002 With Bumper

GUOMAT 1B5330D Cross OEM :

GUOMAT Part Number:1B5330D

Firestone Order Number: W01-358-7009 /

Firestone Order Number:WO13587009 /

Firestone Order Number:WO1-358-7009/

Firestone Order Number:W013587009 /

Firestone Order Number:W01 358 7009

Firestone Part Number:W01-358-7009 /

Firestone Part Number:WO13587009 /

Firestone Part Number:WO1-358-7009 /

Firestone Part Number:W013587009 /

Firestone Part Number:W01 358 7009

Firestone Bellows Number: 19

Contitech Part Number:FS 330-11 468

Contitech Part Number:FS 330 11 468

Contitech Part Number:FS 33011468

Goodyear Part Number:1B12-301 /

Goodyear Part Number:1B12 301 /

Goodyear Part Number:1B12301 /

Goodyear Part Number:1B12-313

Goodyear Part Number:1B12 313

Goodyear Part Number:1B12313

Goodyear Bellows Number:578-91-3-301 /

Goodyear Bellows Number:578 91 3 301 /

Goodyear Bellows Number:578913301

Triangle Part Number:4468

Triangle Bellows Number:6374

SAF Holland : 90557002

SAF Holland :AR741
Ridewell : 1003587009C

GUOMAT 1B5330D Refer to W01-358-7009 Firestone Specifications

❶Bolts

Top Cover Plate Screw (Nut) Tooth : 2 pcs X 1/2-16UNC

Screw Center Distance of Top Cover Plate : 157.5 mm

Bottom Cover Plate Screw (Nut) Tooth :2 pcs X 1/2-16UNC

Screw Center Distance of Bottom Cover Plate : 157.5 mm

❷ Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4NPT

Center Distance Between Nut and Air inlet: 73 mm

❸ Cover Plate

Top Cover Plate Diameter (Width): 231 mm

Bottom Cover Plate Diameter (Width): 231 mm

❹Rubber Bellows

Rubber Bellows MAX Diameter : 325mm

Compressed Height: 68mm

Maximum Height: 160 mm

Min Height: 68 mm

Working Stroke : 92mm

❺ Bumper block / Buffer block

With Bumper Block

❻ Girdle Hoop / Girdle Ring

With Girdle Hoop :no Piece of Girdle Hoop
