Specifications
Brand Name :
Sokkia
Model Number :
IM105
Certification :
CE
Place of Origin :
Japan
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 set per month
Delivery Time :
3-5 days
Packaging Details :
Carton
product name :
total station
Accuracy :
5”
Dust/Water Rating :
IP66 (IEC 60529:2001)
Description

IM101 IM105 Sokkia total station 1 angle accuracy Reflectorless range of 500m total station

The iM-100 (Intelligent Measurement Total Station) incorporates all the features you need at a cost-efficient price. It will handle your most demanding survey layout or as-built project needs.

This total station has a reflectorless range of 2,624 feet and up to 19,685 feet using a single prism at 2.0 mm + 2 ppm accuracy. It is also integrated with Bluetooth Class 1.5, RS-232C serial port, and USB 2.0 for connecting and transferring data instantly to a data controller.

You get fast, accurate, and powerful EDM technology, best-in-class accuracy up to 5,000 m with a prism and up to 800 m in reflectorless mode, and a battery life of up to 28 hours. The iM-100 is ready to be your hardest worker out in the field. Featuring a coaxial red laser using EDM technology, the Sokkia iM-100 is faster, more accurate and powerful. It is equipped with a laser plummet and dual-axis compensation which provides stable measurements even on challenging terrain by automatically correcting both horizontal and vertical angles. This reflectorless total station comes with a single graphic display for viewing measurements and 50,000 points of internal memory to store large amounts of field data. It also supports an SD flash drive up to 32GB.

Features:

  • Fast, accurate and powerful EDM
  • Integrated Blueooth technology - no external antenna necessary for connectivity with the controller
  • Dual axis compensation
  • Waterproof IP66 rating
  • Up to 28 hours of battery life in Eco mode

Sokkia iM-100 Series Reflectorless Total Station is available in four different accuracies as follows:

Technical Spesification

Model Sokkia iM-102 Sokkia iM-103 Sokkia iM-105
Telescope
Magnification / Resolving power 30x / 2.5”
Length 171 mm (6.7 in.)
Objective aperture 45 mm (1.8 in.) (48 mm (1.9 in.) for EDM)
Angle Measurement
Display Resolution 1” / 5”
Accuracy (ISO 17123-3:2001) 2” 3” 5”
Memory
Internal memory Approx. 50,000 points
Plug-in memory device USB flash memory (max. 32GB)
General
Dust/Water Rating IP66 (IEC 60529:2001)
Size with handle (w x d x h) Control panel on both faces: 183 x 181 x 348 mm
Control panel single face: 183 x 174 x 348 mm
