Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
Specifications
Brand Name :
HFMED
Model Number :
HFP-DD240/380 for Surgical
Certification :
CE,ISO,SGS
Place of Origin :
Shanghai,China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, Western Union, T/T
Supply Ability :
500 sets/month
Delivery Time :
3~7 days after payment received
Packaging Details :
carton or wooden case
Arm Length :
1100mm
load capacity :
350 kg
Column length（L=1100mm) :
1 PC
Guideway extension arm（240x240mm) :
1 PC
Gas socket （German Standard import)（O2x1,Airx1,Vacx1) :
3 PCS
Multi-purpose power socket :
6 PCS
Communication Socket RJ45 :
1 PC
Shelf(400*510mm) :
2 PCS
Stainless steel basket :
1 PC
height adjustable infusion rack( Stainless steel ) :
1 PC
Description

Single arm ceiling mounted surgical instruments medical pendant with Gas terminal

Features Description

1. Pendant Applicative Area: Surgical Room/ Emergency Room/ICU/Recovery Room

2. Ceiling Mounted installed.Within 340°revolved,Adjustterminal box location,convience for medical staff operation.

3.The suspension arm is imported by high-strength aluminum alloy extrusion, surface designed by the first level oxidized rust prevention.

4. Friction brake + Pneumatic brake,adopted by German Standard Gas terminal(Insert and Pull more than 20,000 times.)

SPECIFICATIONS

Type HFP-DD240/380 Medical Pendant(for Surgical ) Type 1
The load capacity for Pendant 350Kg
Column length 1000mm
Arm Double ,1100mm
Arm Rotating Angle 340°
Braking System Friction brake+gas brake
Medical Gas Outlets Standards British,German,French,Metric, Ohmeda,DISS,Chemetron, Purit-Bennett Standards Optional

STANDARD CONFIGURATION

Medical Gas Outlets For O2 1
Medical Gas Outlets For Vacuum 1
Medical Gas Outlets For Medical Air 1
Electric Socket 6
Equipment Shelves 2
Drawer 1
Stainless steel basket 1
Communication Socket RJ45 1

Delivery&Warranty

Warranty 1 year
Term 100% T/T
Delivery 7 days after payment received

Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
Ceiling Mounted Medical Pendant Systems Single Arm With Gas Terminal
FAQ

Q1. Can I have a sample order for pendant?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2 .How to proceed an order for hospital pendant?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
