Specifications
Brand Name :
SUNWAY
MOQ :
20 T
Price :
USD1000/T-USD1200/T
Payment Terms :
L/C,T/T
Supply Ability :
100000T/Year
Delivery Time :
30-40 days
Packaging Details :
Steel Pallet
Weather Resistance :
Yes
Cost :
Affordable
Customization Options :
Available
Raw Steel Material :
Q235B, Q355B, ASTM A36, ASTM572
Application :
Steel Structural Building
Color :
Optional
Production Capacity :
12500T Per Month
Standard :
AISC, ASTM, EN, BS, DIN, GB, JIS
Fire Resistance :
Yes
Design :
Customized
Durability :
High
Surface Treatment :
Painting or Hot-dip Galvanized
Columns And Beam :
H Section Column&Beam
Size :
Customized
Customizable :
Yes
Description

Steel Box Columns: Structural Excellence for Modern Construction

Square Steel Box Columns Structural Excellence For Modern Construction

Steel box columns, also known as rectangular hollow section (RHS) or tubular columns, are high-performance structural members fabricated by welding steel plates into closed rectangular or square profiles. Renowned for their superior load-bearing capacity, torsional resistance, and architectural versatility, they are widely used in high-rise buildings, bridges, and industrial structures.‌

    • ‌Design & Geometry‌:

      • Constructed from four steel plates welded into a hollow cross-section, with customizable dimensions (e.g., 200×200mm to 1000×1000mm).
      • Available in square or rectangular profiles, optimized for axial compression and bending moments.

    • ‌Material‌:

      • High-strength steel grades (S355J2, S460ML) compliant with EN 10025 or ASTM A572 standards.
      • Fire-resistant and weather-resistant coatings (intumescent paint, hot-dip galvanizing) for enhanced durability.

    • ‌Fabrication‌:

      • Precision welding (SAW or GMAW processes) ensures full penetration and compliance with ISO 5817 Class B/C standards.
      • Stiffener plates or diaphragm reinforcements added internally to prevent local buckling under heavy loads.

Square Steel Box Columns Structural Excellence For Modern Construction

Product name Steel Box Columns
Material ASTM; EN; GB;
Surface Painted; HDG

Square Steel Box Columns Structural Excellence For Modern Construction

Square Steel Box Columns Structural Excellence For Modern Construction

OEM service available.

A dedicated team of fast response;

EN1090 & AISC & CWB & JIS Certificated Quality;

Full production line for customized products;

Close to Sea port, Convenient for visit and delivery;

150000M2 Manufacturing Area capable to take large volume

Square Steel Box Columns Structural Excellence For Modern Construction

Square Steel Box Columns Structural Excellence For Modern Construction

Square Steel Box Columns Structural Excellence For Modern Construction
