Suntek Group is a professional contract factory on one-stop solution for PCB/FPC assembly,Cable assembly,Mix technoloty assembly and Box-build assembly.

Suntek Electronics Co.,Ltd,as a major facility,located in Hunan province,China;

BLSuntek Electronics Co.,Ltd,as the new facility,located in Kandal province,Cambodia.

With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified.We deliver qualified products with competitive price to clients all over the world.We have the advanced manufacturing equipments,proficient technology,professional engineer team,purchasing team,quality team and management team to guarantee the high quality products and on time delivery.

Our products are widely used in industrial control,auto,telecommunications,medical equipment,consumer electronics and etc.

core is "Quality wins Market, Ideas create the Future".

Key specifications/special features:
Layers: 1-22 layers
Materials: CEM1, CEM3, FR-4, High Tg FR-4, Aluminum board ,
CE: RoHS/UL/ISO9001, ISO13485, TS16949
PCB thickness: 1.6 ±0.1mm
Max. board Thickness: 6.0mm
Testing: 100% E-tested
Surface finished:Lead free,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver


What can we do for you?

1. PCB fabrication
2. PCB assemblies (SMD, BGA and DIP through-hole)
3. Components sourcing or substitute component sourcing
4. Quick-turn prototype and mass production
5. Box build assemblies
6. Tests (X-ray, AOI and functional test)
7. One-stop pcb assemblies manufacturing service

Our Advantage :
Quick response
Reasonable price based on good quality
Provide one-stop service(components, OEM)
Reliability
All products made are according to your design files. We follow your product files in customizing PCBs and PCB assemblies. we assurance that all items come with 1-year warranties.
Confidentiality
We protect the intellectual property for our customers in the whole process. All employees have a strict sense of confidentiality, and working under strict confidentiality agreement.
Flexibility
Custom PCB prototype ,small pcb assemblies orders,such as SMD, BGA and through-hole. PCB prototype leadtime of 3 to 5 working days. PCBA standard production leadtime of 7-10 working days.

RFQ
1.PCB inquiry: Need pcb Gerber or original file , technical description and quantity.
2.PCBA inquiry: Need PCB Gerber file, BOM List and quantity.
3.PCB / pcba clone: Need 2 pcb samples, to make PCB gerber file , bom list .

Shipping Information
FOB Changsha,FOB Shenzhen
Lead Time3–5 days
Weight Per Unit0.5 Kilograms
Dimensions Per Unit25.0 x 14.0 x 1.0 Centimeters
US HTS Code8534.00.10 00
Units per Export Carton100.0
Export Carton Dimensions45 x 35 x 20 Centimeters
Export Carton Weight22.5 Kilograms

Main Export Markets
- Asia
- Australasia
- Central/South America
- Eastern Europe
- Mid East/Africa
- North America
- Western Europe

Payment Details
Payment Method Telegraphic Transfer in Advance (Advance TT, T/T)
