Specifications
Brand Name :
Suntek/BLSuntek
Model Number :
F1062-109
Certification :
ISO9001 ISO13485 IATF16949 UL
Place of Origin :
China or Cambodia
MOQ :
No Limited
Price :
Customized products
Payment Terms :
T/T
Delivery Time :
5-7days after all components kitted
Packaging Details :
By ESD bags and carton
Material: :
FR4(Tg130-Tg180)/Rogers/Aluminum
Solder Mask: :
Green,Blue,Black,Red,White,Matt Color
Copper: :
0.5OZ-10OZ
Layer: :
1L-32L
SMT,THT: :
Yes
Thickness: :
1.0mm/1.6mm/2mm/4mm
RoHs: :
Lead Free
Warranty: :
1year
Hole Min.: :
0.1mm
Description
Industry Automation Control PCB Assembly SMT THT AOI X-Ray FT with 100% E-Test
Professional PCB assembly services featuring green solder mask and comprehensive 100% electrical testing for quality assurance.
About Suntek Group
Suntek is a leading contract supplier in the EMS field, providing comprehensive one-stop solutions for PCB/FPC assembly, cable assembly, and box-build assembly.
Our manufacturing facilities include:
  • Suntek Electronics Co., Ltd - Hunan Province, China
  • BLSuntek Electronics Co., Ltd - Kandal Province, Cambodia
Certified with ISO9001:2015, ISO13485:2016, IATF 16949:2016 and UL E476377, we deliver qualified products with competitive pricing to clients worldwide.
Our Comprehensive Services
We transform your requirements into finished products:
  • Gerber file and BOM conversion into real products
  • Reverse-engineering services from physical samples
  • Joint-design services to bring your ideas to life
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
Technical Specifications
Specification Details
Material Type FR-1, FR-4, CEM-1, aluminum clad
Material Thickness (mm) 0.4, 0.6, 0.8, 1.0, 1.2, 1.6, 2.0
Layer Count 1 to 8 Layers
Max. Board Size 23.00" x 35.00" (580mm*900mm)
IPC Class Class II, Class III, Class 1
Annular Ring 5 mil/side or Greater (Min. Design)
Finish Plating HASL, Lead Free HASL, ENIG, OSP, immersion silver, immersion tin, immersion nickel, hard gold
Copper Weight 0.5OZ-2OZ
Trace/Space Width 3 Mils or greater
Drill Clearance 0.1mm (laser drilling)
Plated Slots 0.036 or greater
Smallest Hole (finished) 0.1mm or greater
Gold Fingers 1 to 4 Edge (30 to 50 Micron Gold)
SMD Pitch 0.080" - 0.020" - 0.010"
Solder Mask Type LPI Glossy, LPI-Matte, SR1000
Solder Mask Color Green, red, blue, black, white, yellow
Legend Color White, yellow, black, red, blue
CNC Route Point Any
Minimum Route Width 0.031"
Scoring Straight lines, jump scoring, panel edge to edge, CNC
Body Gold HARD, IMMERSION (up to 50 MICRON GOLD)
Data File Format Gerber 274x with embedder aperture
FAB. Drawing Format DXF, HPGL, DWG, PDF, Gerber
E.T Testing Flying probe, single sided, 1up plate, clamp shell, net list
Counter Sink/Counter Bore Available up to 0.250 Diameter
Control Impedance Yes
Blind Vias/Buried Vias Yes
Peelable Mask Yes
Carbon Yes
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
Complete Manufacturing Solutions
  • PCB/FPC fabrication
  • Components sourcing
  • PCB/FPC assembly
  • Custom cable/harness assembly
  • Box build assembly
Assembly & Testing Services
  • SMT, THT, BGA, 0201 Chips assembly
  • AOI, X-Ray, ICT, FT, Burn-in testing
  • Conformal coating or gluing
  • High-mix, small to medium volume production
  • ISO9001, ISO13485, TS16949 and UL certified
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
EMS Quality Advantages
  • Strict product liability following IPC-A-610 standards
  • Fluent English-speaking teams
  • PDCA management tool implementation
  • 100% electrical testing and visual inspection
  • Comprehensive AOI inspection including X-ray, 3D microscope and ICT
  • High-voltage testing and impedance control testing
  • ISO9001, ISO13485, IATF16949 and UL certified
  • No minimum order quantity requirements
  • Specialized in low to medium volume production
  • Quick and reliable on-time delivery
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
Why Choose Suntek?
As an experienced and reliable manufacturer, Suntek provides comprehensive one-stop services including PCB manufacturing and assembly for global customers with diverse project requirements.
Instant Quote Service
Receive our detailed quote within 24-48 hours with positive feedback on all project specifications.
Expert Technical Support
Our professional engineers provide comprehensive technical support from PCB design to turnkey assembly.
Advanced Automation
State-of-the-art automatic equipment ensures high efficiency, cost-effectiveness, and consistent quality.
Dedicated After-Sales Service
Continuous order tracking with instant updates throughout the production process from our customer service team.
Customer Support & Services
We maintain complete cost transparency with detailed BOM cost breakdown sharing and source components globally.
Proactive Communication
  • Customer service procedures
  • RMA procedures
  • 8D reports for issue resolution
  • PDCA (Plan-Do-Check-Action) methodology
Responsive Support
  • 24-hour response to complaints and queries
  • Weekly progress reports
  • Dedicated customer support team
  • Customer satisfaction surveys
Comprehensive After-Sales
  • 1-year guarantee period for all products
  • Free-of-charge repair services
  • Rapid replacement of defective components
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
PCBA Assembly Process Flow
Turnkey PCB Assembly with 100% E-Test, 1L-32L Layers, and FR4(Tg130-Tg180)/Rogers/Aluminum Materials
Frequently Asked Questions
Q1: What files do you use in PCB fabrication?
A1: Gerber files and PCB Auto CAD formats.
Q2: How do you ensure product quality?
A2: All products undergo 100% electrical testing. PCB assemblies include comprehensive AOI, ICT, functional testing, and 100% X-ray inspection for BGA components.
Q3: Can we visit your facilities?
A3: Absolutely. We welcome visits to our Suntek facility located in Xingsha Industrial Park, Changsha, Hunan province, China.
Q4: What are your typical lead times?
A4: Samples: 3-5 working days; Batch production: 7-10 working days (based on files and quantity); PCB assembly: 15-20 working days.
Q5: How do you protect customer information?
A5: We strictly maintain business confidentiality and protect customer designs. NDAs can be signed at any time.
Q6: How do we start working with you?
A6: Email your PCB layout file and BOM list. We provide confirmation within 12 hours and detailed quotes within 3-5 days.
