Stainless Steel Clad 304L Fixed Tube Sheet Heat Exchanger for MDI
Stainless Steel Clad 304L Fixed Tube Sheet Heat Exchanger for MDI
Specifications
Brand Name :
Suntech or OEM
Model Number :
PV0118
Certification :
U Stamp / PED / ISO / SGS / NB
Place of Origin :
China
MOQ :
1 set
Price :
negociation
Payment Terms :
L/C, T/T,etc.
Supply Ability :
300 Pieces/Year
Delivery Time :
90 working days after received your payment
Packaging Details :
Seaworthy packing
Material :
304L + 516 Gr.70
Pressure :
0.1 Mpa – 3.6 Mpa
Surface :
700 sqm
Weight :
28 Tons
Description

Stainless Steel Clad 304L Fixed Tube Sheet Heat Exchanger for MDI

Detailed Product Description:

Material: Tubesheet: 304L

Shell side:304L + 516 Gr.70

Pressure: 0.1 MPa – 3.6 Mpa

Media: Toxic

Application : MDI

Length: 9000 mm

Diameter: 2000 mm

Surface: 700 sqm

Weight: 28 Tons

Working Temp.: 200 ℃

Product advantage:

-Clad vessels provide an economical solution for chemical processing;

-Stainless steel surface contains sufficient chromium to form a passive film of chromium oxide, preventing further surface corrosion by blocking oxygen diffusion to the steel surface and blocks corrosion from spreading into the metal's internal structure;

- Technical consulting on material, thickness suggestion, welding, NDE, etc.
