25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
Specifications
Brand Name :
MEAN WELL
Model Number :
LCM-25
Certification :
RoHS,CE,TUV,CER,EMC
Place of Origin :
Shenzhen,China
MOQ :
10
Price :
Need to negotiate
Payment Terms :
T/T,PAYPAL,Western Union,Money Gram
Supply Ability :
10000pcs/month
Delivery Time :
7-10 work days
Packaging Details :
carton
Power :
18.9W/25.2W
Input Voltage :
AC180-277V
Material :
Aluminum case
Warranty :
3 years
Description
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
Product Overview
The LCM-25 series is a 25W AC/DC constant current mode output LED driver featuring multiple levels selectable by DIP switch. Operating from 180-277VAC, it offers current levels ranging between 350mA and 1050mA. With efficiency up to 86% and fanless design, this series operates within -30℃ to +85℃ case temperature under free air convection. The LCM-25 includes dimming functions and synchronization capabilities for optimal design flexibility in LED lighting systems.
Key Features
  • Constant Current mode output with multiple levels selectable by DIP switch
  • Plastic housing with Class II design
  • Built-in active PFC function
  • Standby power consumption <0.5W
  • Functions: 3 in 1 dimming (dim-to-off); synchronization up to 10 units
  • 3 years warranty
Technical Specifications
MODEL LCM-25
CURRENT LEVEL Current level selectable via DIP switch, please refer to "DIP SWITCH TABLE" section
350mA 500mA 600mA 700mA(default) 900mA 1050mA
RATED POWER 18.9W 25.2W



DC VOLTAGE RANGE 6 ~ 54V 6 ~ 50V 6 ~ 42V 6 ~ 36V 6 ~ 28V 6 ~ 24V
OPEN CIRCUIT VOLTAGE (max.) 59V 41V
CURRENT RIPPLE 5.0% max. @rated current
CURRENT TOLERANCE ±5%
SETUP TIME 500ms / 230VAC
VOLTAGE RANGE 180 ~ 277VAC 254 ~ 392VDC
(Please refer to "STATIC CHARACTERISTIC" section)
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF≥0.94/230VAC, PF≥0.91/277VAC @full load
(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
TOTAL HARMONIC DISTORTION THD<20%(@load≥50%/230VAC; @load≥75%/277VAC)
(Please refer to "TOTAL HARMONIC DISTORTION(THD)" section)
EFFICIENCY (Typ.) 86%
AC CURRENT (Typ.) 0.17A/230VAC 0.15A/277VAC
INRUSH CURRENT (Typ.) COLD START 20A(twidth=260μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER 26 units (circuit breaker of type B) / 44 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT <0.5mA / 240VAC
STANDBY POWER CONSUMPTION <0.5W
25W Dimmable Constant Current LED Driver with Aluminum Case for Indoor Lighting
Applications
  • LED indoor lighting
  • LED office lighting
  • LED architectural lighting
  • LED panel lighting
Shipping & Payment Informations
Shipping Method Delivery Time
DHL/UPS/TNT/FEDEX 4-5 working days
EMS 10-15 working days
HK Post Air Mail Register 15-18 working days
Trade Terms FOB | EXW | CNF
Sample Availability YES
Standard Delivery Time 3-4 working days
