50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
Specifications
PCB size :
115.59x115.59x1.5mm
PCB circuit :
8 series 8 parallel
Beam angle :
80x150 degree
LED chip :
3030 SMD LED, 140-150lm/w@ 150mA,6v
Transmittance :
91%
Brand Name :
Sunshineopto
Model Number :
SUN-J64-3030-80x150
Certification :
SGS,RoHS,CE
Place of Origin :
Shenzhen,China
MOQ :
50
Payment Terms :
T/T,PAYPAL,Western Union,Money Gram
Supply Ability :
5000pcs/months
Delivery Time :
7-10 working days
Packaging Details :
Cartons
Price :
negotiate
Lens size :
130x130x6.9mm
Description
50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
Product Overview

A 72-position SMD 3030 LED array, combined with an optical-grade PC array lens, silicone gasket and matching aluminum PCB. Published specifications list a nominal 50W application, an 80×150° asymmetric beam angle, approximately 91% lens transmittance, a lens size of approximately 250 × 74 × 6.15 mm, and a PCB size of approximately 226 × 57.9 × 1.5 mm.

Key Features
  • This SKD 64 LED Array lens with PCB Module is best designed for power lamps like 50-55W/100-110W and similar applications
  • Lowest total cost solution that can replace existing Metal Halide or HPS bulbs while reusing old housings
  • Industry-leading thermal management technology
  • Operating temperature range: from 35°C to 70°C
  • Contains no mercury or lead
  • Does not produce UV rays that harm eyes
  • Directional light means no light pollution, dark sky compliance
  • Optic lenses available for projects needing smaller beam angles like 90°, 120°, and TYPE4
Technical Specifications
Model No. SUN-J64-3030-80x150
Main parts 64 Array lens+silicon gasket + PCB + LED
Lens material PC
Lens size 130x130mm
PCB size 115.59x115.59x1.5mm
PCB circuit 8 series 8 parallel
Beam angle 80x150 degree
Transmittance 91%
LEDs 3030 SMD LED, 140-150lm@ 150mA, 6v
Quality guarantee If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charge, or offer refund.
Main market Europe, South America, North America, Asia
Product Dimensions

LENS Dimensions:

50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W

Dimensions for silicon gasket:

50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W

Beam pattern - 80x150 Degree:

50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W

Beam pattern - 90 Degree:

50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W

PCB board size:

50W LED Street Light Module with 80×150 Degree Asymmetric Lens 3030 SMD LED PCB Board Up to 160 lm/W
Applications

Street lights, highway LED lamps, tunnel lamps, square lamps, road lamps, city lighting, parking spot lamps, track lighting fixtures, scenery areas, retail lighting, and other applications where high luminous flux is desired.

Shipping & Delivery Informations
DHL/UPS/TNT/FEDEX 4-5 working days
EMS 10-15 working days
HK Post Air Mail Register 15-18 working days
Trade Terms FOB | EXW | CIF | CFR
Sample availability YES
Delivery time 3-4 working days

FAQ

Is the module really 160 lm/W?

The published product information refers to a 3030 LED platform with efficacy up to approximately 150–160 lm/W under stated LED test conditions. The final efficacy of a complete street-light fixture will depend on the optical, thermal and electrical system design.

Can it replace a metal-halide or HPS street light?

The module can be used in compatible retrofit projects, potentially allowing existing housings to be reused, but the thermal capacity, electrical system and mechanical dimensions must be verified.

Can I buy the lens separately?

Yes. The optical lens can be supplied separately or as part of an integrated LED module configuration.

Can you supply the PCB and LEDs together?

Yes. The module architecture can include the optical lens, silicone gasket, PCB and 3030 SMD LED array, depending on project requirements.

Can the PCB and lens be customized?

Yes. Custom PCB dimensions, LED layouts, beam distributions and mechanical interfaces can be evaluated for OEM and ODM projects.
