ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
ASCO Series 290 Pressure Operated Piston Solenoid Valve Direct Acting OEM
Specifications
Brand Name :
ASCO
Model Number :
ASCO™ 290 Angle-Body Piston Valve
Place of Origin :
china
MOQ :
2
Price :
$400
Payment Terms :
T/T
Supply Ability :
>100
Valve Actuation :
Motorized, Pneumatic - Air Pilot
Media :
Aggressive Liquids/Gases, Air, Inert Gas, Fuel Oil, Hot Water, Light Oil, Oxygen, Steam, Water
Pipe / Port Size :
1/2 "; 3/8 "; 3/4 "; 1 "; 1 1/4 "; 1 1/2 "; 2 "; 2 1/2 "
Port Type :
G ISO228/1-G BSPP, NPTF
Function :
2 way - 2/2 Normally Closed, 2 way - 2/2 Normally Open
Flow :
From 2.0 Cv to 6.0 Cv, From 6.0 Cv to 14.0 Cv, Over 14.0 Cv
Operating Environment :
Indoor, Outdoor
Standards / Regulations :
RoHS, Type 4, Type 4X
Description

ASCO Series 290 A Pressure Operated, Direct Acting Angle-Body Piston Solenoid Valve

Product Description

The ASCO Series 290, also known as 8290, is a pressure-operated, direct acting angle-body piston solenoid valve built for demanding applications. Its straight-through body design is available in bronze or stainless steel. The valve is suitable for general service applications (air, inert gas, water, oil, and light slurries), plus steam, hot water, and auxiliary fluids within the food and beverage industry. Many optional features available including a visual/electrical position indicator or a stroke limiter.

Product Features


Proven durability in handling aggressive fluids such as steam, hot water, solvents, and light slurries
Optional features include position indication and proportional control
Rugged water-tight actuator made from tough fiber composite and protected with a double O-ring seal
Spring-loaded stem seal: FKM fluoroelastomer wiper keeps harmful grit way from the stem area for exceptional durability
Smooth stem movements guided by two oversized bearings for maximum reliability
Anti-water hammer design: fluid passes under the disc resulting in slower closure
Some versions are compatible with FDA CFR21 for food and beverage applications

Specification

item

value

structure

Control

application

General

place of origin

United Kingdom

power

Hydraulic

customized support

OEM

port size

1/2

warranty

1 years

model number

E290B010

temperature of media

Normal Temperature

brand name

ASCO

media

Gas

Maximum allowable pressure

16bar

temperature range

-10°C to +60°C

Maximum viscosity

600 cSt (mm2 /s)

Max. pilot pressure

10 bar
