AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
Specifications
Brand Name :
ASCO
Model Number :
Multi-Rod Pneumatic Cylinder Series 15552-PRA
Place of Origin :
china
MOQ :
2
Price :
186
Payment Terms :
T/T
Supply Ability :
>10
Packaging Details :
each
Product_Name :
Rodless Cylinder
Action :
Double Acting
Piston_Type :
Magnetic, Non-Magnetic
Cushioning :
Adjustable
Mounting_Type :
Foot, Flange, Clevis, Trunnion
Accessories :
Sensors, Switches, Mounting brackets
End_Cap_Type :
Threaded, Flange
Type :
Pneumatic
Guide_Type :
External, Internal
Description
Product Description:

The AVENTICS Series PRA (ISO 15552) cylinders are a game - changer in the world of industrial components. Their compact design profile, featuring integrated sensor slots, not only saves space but also enables easy sensor installation.These cylinders are incredibly versatile, suitable for all industries. Whether it's general automation technology, machine and systems construction, or specific industry applications, the Series PRA cylinders deliver reliable performance. They come in piston diameters ranging from 32 mm to 125 mm, with advanced pneumatic end - position cushioning and additional elastic damping elements for smooth operation.With a modular sealing system, they offer great adaptability. Explore the wide range of variants and accessories available in the configurator. Choose AVENTICS Series PRA for efficient, durable, and customizable cylinder solutions.

Product Features:

  • 6 mm T-slots and 4 mm C-slots allow for a large number of sensors to be mounted easily, quickly and compactly
  • Available in piston diameters from 32 mm to 125 mm
  • Modular sealing system allows for adaptability
  • Advanced pneumatic end position cushioning
  • Additional elastic damping elements
  • Wide range of variants and accessories available in the configurator

DESCRIPTION:

Specification

Details

Piston Rod Modification

Through

Functional Principle

Double - acting

Cushioning

Pneumatically adjustable

Magnetic Piston

With magnetic piston

Piston Diameter

40 mm

Piston Rod Thread

M12x1.25

Standardization

ISO 15552

Stroke

25 mm

Sealing Material

Polyurethane

Scraper

Polyurethane

Compressed Air Connection

G 1/4

Compressed Air Connection Type

Internal thread

Standards

ISO 15552

Working Pressure Min./Max.

1.5 … 10 bar

Ambient Temperature Min./Max.

-20 … 80 °C

Medium Temperature Min./Max.

-20 … 80 °C

Medium

Compressed air

Max. Particle Size

50 µm

Oil Content of Compressed Air

0 … 5 mg/m³

Pressure for Determining Piston Forces

6.3 bar

Pressure Dew Point Requirement

At least 15 °C under ambient and medium temperature and may not exceed 3 °C

Oil Content Requirement

Must remain constant during the life cycle. Use only approved oils from AVENTICS. Further info in “Technical information” (MediaCentre).

Material - Cylinder Tube

Aluminum, anodized

Material - Piston Rod

Stainless steel

Material - Front Cover

Die - cast aluminum

Material - End Cover

Die - cast aluminum

Material - Seal

Polyurethane

Material - Nut for Piston Rod

Steel, galvanized

Material - Scraper

Polyurethane

Product Details:

AVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable CushioningAVENTICS Multi Rod Pneumatic Rodless Cylinder 15552-PRA Adjustable Cushioning
