AVENTICS Diaphragm Type Dryer Series NL4 – ADD – R412007607 Easy To Assemble
AVENTICS Diaphragm Type Dryer Series NL4 – ADD – R412007607 Easy To Assemble
Specifications
Brand Name :
AVENTICS
Model Number :
Series NL4 – ADD – R412007607
MOQ :
1
Price :
$255
Payment Terms :
T/T
Supply Ability :
100
Packaging Details :
Packaging and delivery Selling Units: Single item Single package size: 6X6X6 cm Single gross weight: 1.000 kg
Description

Product Description:

The AVENTICS Series NL maintenance units are highly versatile. They can be used as single components or assembled units, catering to both centralized and decentralized compressed air preparation. Available in compact or powerful versions, they function well in extreme temperatures. This line provides a fully customizable compressed air preparation solution. Each component in the series can be combined to meet specific application needs, ensuring a perfect fit. Among them, the AVENTICS Diaphragm – type dryer, Series NL4 – ADD – R412007607, efficiently removes moisture, guaranteeing clean and dry compressed air for optimal performance in various industrial processes.

Product furtures:

  • Easy-to-assemble
  • Manual, semi-automatic or fully-automatic condensate drains available
  • Transparent reservoirs available
  • Bayonet catches ensure easy maintenance

DESCRIPTION:

Parts Diaphragm-type dryer
Housing Die cast zinc
Reservoir Aluminum
Sealing material Acrylonitrile butadiene rubber
suitable for ATEX
Nominal flow Qn 650 l/min
Compressed air connection G 1/2
Version Diaphragm-type dryer
Parts Diaphragm-type dryer
Mounting orientation vertical
Certificates suitable for ATEX
Working pressure min./max. 4 … 12,5 bar
Ambient temperature min./max. 2 … 60 °C
Medium temperature min./max. 2 … 60 °C
Medium Compressed air Neutral gases
Filter element not exchangeable
Lowering pressure dew point 20 °C
Weight See table
The pressure dew point must be at least 15 °C under ambient and medium temperature and may not exceed 3 °C .
Notice: air may not contain condensate
purge air approx. 12% of nominal flow Qn
Suitable for use in Ex zones 1, 2, 21, 22.
A change in the flow direction (from air supply on the left to air supply on the right) occurs by rotating installation by 180° about the vertical axis. Please see the operating instructions for further details.
Recommended pre-filtering ?m 5 / 0,01 µm
Material
Housing Die cast zinc
Front plate Acrylonitrile butadiene styrene
Seal Acrylonitrile butadiene rubber
Reservoir Aluminum

Product Details:

AVENTICS Diaphragm Type Dryer Series NL4 – ADD – R412007607 Easy To AssembleAVENTICS Diaphragm Type Dryer Series NL4 – ADD – R412007607 Easy To Assemble
