Specifications
Brand Name :
Yan Yang Tian
Model Number :
Non-standard customized equipment
Place of Origin :
Jiangsu,China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
5 Sets per Month
Delivery Time :
Negotiable
Packaging Details :
Export package or according the customer's requirement
Voltage(V) :
220V/380V
Operating temperature :
1000℃
Brand :
Yan Yang Tian
Temperature control accuracy :
±1ºC
Name :
Box experiment electric furnace
Description

1400 ℃ Box Experiment Electric Furnace Series Can Be Customized

1, Main feature
  • Chamber material is composed of 1600 ℃ ceramic fiber calcined board, which has good thermal insulation performance and can quickly heat up
  • Using the intelligent digital display programmable temperature control table, it can compile multi-section rising, maintaining and cooling curves, automatic heating, heat preservation, cooling and over-temperature protection. The program will automatically stop at the end of the program operation, no need to watch, temperature control accuracy ± 1ºC
  • The heating element is silicon carbon rod, which is convenient and fast to maintain, and the long-term use temperature is within 1350 ℃
  • According to the need, the furnace can be flushed with: nitrogen, argon, and other protective gases
2, Standard models are below

Electric furnace model Operating temperature(°C) Chamber size (mm) power(KW) Voltage(V)

TC—14X1

1000 200×150×150 3 220

TC—14X2

1000 300×200×200 6 380

TC—14X3

1000 400×300×200 9 380

TC—14X4

1000 500×300×300 12 380
Please contact us for more details, we will tailor-made for you!
3, Product application field
Uses: used for thermal testing of laboratories in universities and research institutes
1400 ℃ Box Experiment Laboratory Electric Furnace
