Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift
Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift
Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift
Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift
Specifications
Brand Name :
SUNNY
Model Number :
Home elevator
Certification :
3C,CE
Place of Origin :
China
MOQ :
1 set
Price :
$7000~12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 Set/ Year
Delivery Time :
15~30 days
Packaging Details :
container
Name :
Home Elevators Lift
Load :
450-1600kg
Speed :
1.0~1.75m/s
Machine Room :
with and Without
Warranty :
12 months after shipping
Application :
Office Building
Floor :
PVC
Door Knife :
Single
Model :
Home Elevators Lift
Product name :
Home Elevators Lift
Description

0.4m/S Vvvf Control Observation Lift Home Villa Observation Elevator Lift

About passenger elevator

A vertical elevator powered by a motor, equipped with a box-like pod, used for multistory building passengers. Fixed lifting equipment for specified floors. It has a car running between at least two vertical rigid guides.
Car size and structure for passenger access and loading and unloading. It is customary to use the elevator as a general term for vertical transportation in buildings, regardless of the driving mode.

Standard Decoration Optional(if you have other request,we can provide)

It's wall Hairline stainless steel
Ceiling LED Fluorescent, according to the car design
Car bottom PVC
Jamb material The first layer of hairline, the remaining steel plate Spraying
Hall door The first layer of hairline, the remaining steel plate Spraying

Passenger Elevator Parameter

Load capacity
(Kg)		 Rated Speed
m/s		 Car Size
cw*cd(mm)		 Door Opening
Size ew*eh(mm)		 Shaft
Size hw*hd(mm)		 Top
floor height
Th(mm)		 Pit Depth
(mm)
450 1 1100×1100 800×2100 2050×1850 4500 1500
630 1 1400×1100 800×2100 2250×1900 4500 1500
1.5 4700 1600
1.75
800 1 1400×1350 800×2100 2200×1950 4000 1500
1.5/
1.75		 4700 1600
1000 1 1500×1550 900×2100 2350×2150 4000 1600
1.5/
1.75		 4700 1600
1600 1 1800*2000 1100*2100 2900*2200 4350 1500
1.5/
1.75		 4500 1600

Construction Sketch

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

STANDARD CONFIGURATION

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift

Vvvf Luxurious 800kg 0.4m/S With Residential Home Elevators Lift


FAQ
1. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.


2. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.


3. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.


4. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
