Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator
Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator
Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator
Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator
Specifications
Brand Name :
SUNNY
Model Number :
Passenger elevator
Certification :
3C,CE
Place of Origin :
China
MOQ :
1 set
Price :
$7000~12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 Set/ Year
Delivery Time :
15~30 days
Packaging Details :
container
Name :
Residential Elevator
Load :
630-1600kg
Speed :
1.0-1.75m/s
Warranty :
12 months after shipping
COP :
Hairline stainless steel
Floor :
Marble
Drive type :
AC
Product name :
Residential Elevator
Control :
VVVF Elevator Control System
Drive system :
AC or DC
Model :
Residential Elevator
Description
630~1600kg Vvvf Passenger Elevator Residential Building Elevator
Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator
Decoration
Ceiling Hairline stainless steel, white acrylic+LED
Cabin panel Hairline stainless steel
Mirror Stainless Steel
COP Hairline stainless steel
Handrail Hairline stainless steel
Floor Marble


Parameter

Load capacity
(Kg)		 Rated Speed
m/s		 Car Dimension
CW*CD(mm)		 Door Opening
Dimension
EW*EH(mm)		 Standard Shaft
Dimension
HW*HD(mm)		 Max Shaft
Dimension
HW*HD(mm)		 Standard Pit Depth
Pd(mm)		 Standard top
floor height
Th(mm)
630 1 1100×1400 700×2100 1850×1850 2550×2450 1500 4250
1.5 1550 4350
1.75 1600 4400
630 1 1100×1400 700×2100 1850×1900 2550×1900 1500 4250
1.5 1550 4350
1.75 1600 4400
800 1 1350×1400 800×2100 2100×1850 2800×2450 1500 4250
1.5 1550 4350
1.75 1600 4400
800 1 1350×1400 800×2100 2100×1900 2800×1900 1500 4250
1.5 1550 4350
1.75 1600 4400
1000 1 1600×1400 900×2100 2350×1850 3050×2450 1500 4250
1.5 1550 4350
1.75 1600 4400
1000 1 1600×1400 900×2100 2350×1900 3050×1900 1500 4250
1.5 1550 4350
1.75 1600 4400
1150 1 1800×1400 1100×2100 2700×1800 3400×2400 1500 4350
1.5 1550 4450
1.75 1600 4500
1250 1 1900×1500 1100×2100 2800×1900 3500×2500 1500 4350
1.5 1550 4450
1.75 1600 4500
1350 1 1900×1600 1100×2100 2800×2000 3500×2600 1500 4350
1.5 1550 4450
1.75 1600 4500
1600 1 2000×1800 1100×2100 2900×2200 3600×2800 1500 4350
1.5 1550 4450
1.75 1600 4500
1600 1 1800×1800 1000×2100 2700×2300 3400×2300 1500 4350
1.5 1550 4450
1.75 1600 4500

Hairline Stainless Steel 1600kg Load Vvvf Residential ElevatorHairline Stainless Steel 1600kg Load Vvvf Residential ElevatorHairline Stainless Steel 1600kg Load Vvvf Residential ElevatorHairline Stainless Steel 1600kg Load Vvvf Residential Elevator

Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator

Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator

Hairline Stainless Steel 1600kg Load Vvvf Residential Elevator

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
