6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS
Specifications
Brand Name :
Sunchonglic
Model Number :
SUNer-D 6500-48
Place of Origin :
China
MOQ :
100pcs
Price :
US $9.09-67.82
Payment Terms :
T/T
Supply Ability :
100000pcs/mon
Delivery Time :
20-60 work days
Packaging Details :
Paper Box
Product name :
6500W 48V Pure Sine Wave Inverter MPPT Hybrid Inverter Charger With UPS DC 24V To AC 220V
AC Output Voltage (VAC) :
208/220/230/240
Frequency :
50/60Hz±0.1%
Solar Charger Type :
MPPT
Max. Efficiency (Battery Mode) :
93%@48VDC
Power Factor (PF) :
1
Description

6500W 48V Pure Sine Wave Inverter MPPT Hybrid Inverter Charger With UPS DC 24V To AC 220V


>>>Product Description


What is feature of 6500w 48v pure sine wave inverter mppt hybrid inverter charger with ups dc 24v to ac 220v?

1.Support Lithium/Lead-acid Battery
2.9 Inverters in Parallel
3.MAX.PV 9KW
4.Built-in 120A Solar Charger
5.Feed-in to Grid
6.Workable with Generator
7.Wide MPPT Range 120-520V
8.WiFi Monitoring
9.Lithium Battery Activation6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS


>>>Product Specifications


Model SUN-D 6500-48
AC Input
Rated Input Voltage (VAC) 208/220/230/240;L+N+PE
Voltage Range (VAC) 90~280±3(normal mode);170~280±3(UPS mode)
Frequency (Hz) 50/60(Auto Adaptive)
AC Output
Rated Capacity (kW) 6
Surge Power (kVA) 12
Voltage (VAC) 208/220/230/240
Power Factor (PF) 1
Frequency 50/60Hz±0.1%
Switch Time (ms) 10 (normal mode)/10(UPS mode)
Wave Form Pure Sine Wave
Overload Capacity (Battery Mode) 10min@102%~1 20%Load, 1min@120%-150%Load
10S@150%-200%Load,5s@>200%Load
Max. Efficiency (Battery Mode) 93%@48VDC
Parallel Quantity NA
Charger (PV/AC)
Solar Charger Type MPPT
Max PV input current / power 19A+19A/9000W
Operating Voltage Range (VDC) 80~520
Max PV Open Circuit Voltage (VDC) 500
Max PV Charge Current (A) 120
Max AC Charge Current (A) 120
Max. Charge Current (PV+AC) (A) 120
Battery
Normal Voltage (VDC) 48
Floating Charge Voltage (VDC) 56
Overcharge Protection (VDC) 60
Battery Type Lithium and Lead-acid
Interface
Reveal LCD
Communication RS485 /USB /Dry Contact /CT/Meter
Monitoring WiFi (Optional)
General Data
Ingress Protection IP21
Operating Temperature -10 °℃~ 50 °℃
Relative Humidity 5% ~95%(Non-condensing)
Storage Temperature -15 *C~ 60 "℃
(NW/GW)Kg 8.7/10.1
Max. Operating Altitude 4000m (Derating above 1000m)
DIMENSION
LxWxH (products size, mm) 331×410×135mm
LxWxH (package size, mm) 471×407×211mm


>>>Our Factory

We are a seasoned manufacturer with extensive years of experience in the production of Solar Energy
Photovoltaic Products. Our factory specializes in manufacturing a diverse range of products, including
Solar Power Inverters, AGM/GEL Lead Acid Battery Chargers, and Solar Charge Controllers, among others.

For additional details,please reach out to us at any time!


>>>Production Process


6500W 48V Pure Sine Wave Hybrid Solar Inverter MPPT Inverter Charger with UPS

>>>FAQ


Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T,Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.


Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
