API 11AX-0061 Sucker Rod Pumps Carbon Steel With Spray Metal Plunger
API 11AX-0061 Sucker Rod Pumps Carbon Steel With Spray Metal Plunger
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Model :
Non standard Model
Seating assembly :
Mechanical seating or cup seating
Plunger material :
Carbon steel
Plunger coating :
Spray metal
Barrel type :
Heavy wall or thin wall
API certificate :
API 11AX-0061
Description

Non Standard Model Sucker Rod Pumps With Spray Metal Plunger

Non standard sucker rod pump Description

Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API-RHBM-AC) , seating nipple connection on the tubing string, down to the bottom of the well with the tubing string.

Plunger assembly connection on the sucker rod string and with the pump overall down to seating nipple position together , pump with fixed inside the seating nipple , Plunger assembly with the sucker rod string up and down reciprocating movement to achieve pumping work.
If the pump appeared quality problem, need not put forward the tubing string, only need put the whole pump forward well through the sucker rod string together , operation is simple.

Rod pump should be installed inside the tubing with the sucker rod. It is not necessary to pull the tubing out of the well when checking the pump, which can make the operation easier and quicker.

API sucker rod pump technical parameters:

API model OD of Pump

Length of Barrel (ft)

Plunger length

(ft)

Stroke length

(ft)

Extension length

(ft)

Tubing size

EUE/NUE

Sucker rod
20-125RWAM Ø31.75

2.1-10

0.3-8

1.2-9

/

 2-3/8” 5/8” 3/4”
20-125RWAC
20-125RWBM
20-125RWBC
20-150RWAM Ø38.10
20-150RWAC
20-150RWBM
20-150RWBC
25-200RWAM Ø50.80 2-7/8”
25-200RWAC
25-200RWBM
25-200RWBC
30-250RWAM Ø63.50 3-1/2”
30-250RWAC
30-250RWBM

Features
1. The non-standard model is designed based on the well conditions.
2. Mechanical seating assembly or cup seating assembly
3. Production standard is still based on the API regulations.
