Sucker Rod Pump Accessries Stellite Alloy Valve Ball And Seat Oilfield Pump Parts
Sucker Rod Pump Accessries Stellite Alloy Valve Ball And Seat Oilfield Pump Parts
Specifications
Brand Name :
Zhongshi
Certification :
API，ISO，QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, D/P, D/A, L/C, Western Union
Supply Ability :
1000 Sets per Month
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Product :
Valve ball and seat for subsurface sucker rod pump
Material :
High Manganese Steel
Features :
High Efficiency
Processing Type :
Casting
Warranty :
12 Months
Application :
Oil Field
Description

Sucker Rod Pump Accessries Stellite Alloy Valve Ball AndValve Seat Oilfield Pump Parts

Product Description

The valve balls and valve seats are main components and parts of the sucker rod pump.

1. API Spec 11A
2. Strong corrosion resistance
3. Excellent mechanical property

Features

1. Hardness and resistance against wear.

2. High compressive strength.

3. With the ability to withstand shock and also impact.

Technical Specifications

Size of ball(mm) Size of ball(mm) Size of ball seat(mm) Size of ball seat(mm)
Ø19.05 Ø19.05 Ø13* Ø15*12 Ø23.32* Ø15*12.7
Ø22.2 Ø23.83 Ø28* Ø18*12 Ø29.67* Ø18.2*12.7
Ø25 Ø28.58 Ø28* Ø19*12 Ø35.26* Ø22.2*12.7
Ø25.4 Ø34.93 Ø30* Ø18*12 Ø43.69* Ø27.4*12.7
Ø29 Ø42.88 Ø34* Ø23*12 Ø51.05* Ø33.6*12.7
Ø32 Ø50.8 Ø47* Ø27*12.7 Ø67* Ø39.9*19.1
Ø35 Ø57.15 Ø44* Ø27*15 Ø67* Ø44.8*19.1
Ø38 Ø63.5 Ø55* Ø30*20 Ø78.4* Ø49.8*19.1
Ø45 Ø69.85 Ø55* Ø36*15 Ø91.1* Ø54.8*19.1
Ø50 Ø74.61 Ø65* Ø40*20 Ø88* Ø63.5*20
Ø50.8 Ø67* Ø41*15
Ø55 Ø67* Ø45*20
Ø60.325 Ø77* Ø50.5*20
Other size as client’s request
