Thin Walled Sucker Rod Pump Rw Model Cup Anchor AISI 1045 Steel
Thin Walled Sucker Rod Pump Rw Model Cup Anchor AISI 1045 Steel
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Pump model :
RW
Barrel type :
Thin walled
Barrel material :
AISI 1045 steel
Barrel coating :
Chrome plated
Plunger material :
AISI 1045 steel
Plunger coating :
Spray metal
Anchor :
Cup anchor
Model :
From 20-125 to 30-250
Description

RW Model Cup Anchor Thin Walled Sucker Rod Pump

RW thin walled sucker rod pump description:

API pump and special pump of Puyang Zhongshi Group

RHAC, RHBM, RHAM , RTH(B)C, TH(B)M, RWBM, RWBC, RWAM, RWAC RHBM, RHBC

Basic characters of pump parts:

The inner surface of the pump barrel is processed with carbonization quench and chrome plating technology

The plunger surface is processed with thermal metal spraying technology

The pump meets the requirement of long stroke, high speed and deep producing

It has the advantages of high pumping efficiency, large displacement, wear and corrosion resistance, long operation and easy repairing.

It accords with API SPEC 11AX standard, and has the certificate of authority to use the official API monogram.

RW thin walled pump technical specification:

Pump model Pump diameter

Barrel length

(ft)

Plunger length

(ft)

Stroke length

(ft)

Extension length

(ft)

Tubing size

EUE/NUE

Sucker rod
20-125RWAM Ø31.75

2.1-10

0.3-8

1.2-9

/

 2-3/8” 5/8” 3/4”
20-125RWAC
20-125RWBM
20-125RWBC
20-150RWAM Ø38.10
20-150RWAC
20-150RWBM
20-150RWBC
25-200RWAM Ø50.80 2-7/8”
25-200RWAC
25-200RWBM
25-200RWBC
30-250RWAM Ø63.50 3-1/2”
30-250RWAC
30-250RWBM

Features:
1. Have cup seating and mechanical seating, mechanical seating is suitable for high temperature oil well
2. The top anchored pump with stationary barrel is suitable for sandy wells.
3. The bottom anchored pump with stationary barrel is suitable for deep wells.

Sucker rod pump packing:

Thin Walled Sucker Rod Pump Rw Model Cup Anchor AISI 1045 Steel
