Stainless Steel Material Rod Inserted Pump Valve Ball And Seat
Stainless Steel Material Rod Inserted Pump Valve Ball And Seat
Specifications
Brand Name :
Zhongshi
Model Number :
RHBM/AC
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Pump type 1 :
Sucker rod pump
Pump type 2 :
Tubing pump
Barrel material :
Carbon steel or alloy steel
Barrel coating :
Chrome plated
Valve ball & seat material :
Stainless steel
API Standard :
API 11AX
Application :
Oil pumping
Oil well suitable :
Normal oil well
Description

Stainless Steel Material Valve Ball And Seat Rod Inserted Pump

Oil Pumping Sucker Rod Pump description

RHBM/AC rod inserted pump is equipped with a cup seating nipple N11, cup seating nipple N11 connection on the tubing string, down to the bottom of the well with the tubing string.

Plunger assembly connection on the sucker rod string and with the pump overall down to cup seating nipple N11 position together , pump with fixed inside the cup seating nipple N11, Plunger assembly with the sucker rod string up and down reciprocating movement to achieve pumping work.

Some features of our rod inserted pump:

1.The inner surface of the pump barrel is processed with carbonization quench and chrome plating technology

2. The plunger surface is processed with thermal metal spraying technology

3. The pump meets the requirement of long stroke, high speed and deep producing

4. It has the advantages of high pumping efficiency, large displacement, wear and corrosion resistance, long operation and easy repairing.

5. It accords with API SPEC 11AX standard, and has the certificate of authority to use the official API monogram.

RHBM/AC series technical specification table:

RHBM/AC model Pump OD (in) Barrel length (ft) Stroke length (ft) Extension length (ft)
20-125RHBM/AC Ø31.75 2.1-10.4 1.2-9.0 0.3-0.9
25-150RHBM/AC Ø38.10
25-175RHBM/AC Ø44.45
30-225RHBM/AC Ø57.15

Tubing type rod inserted pump photo:

Stainless Steel Material Rod Inserted Pump Valve Ball And Seat
