Subsurface Inserted Sucker Rod Pump Double valve For Oil production
Subsurface Inserted Sucker Rod Pump Double valve For Oil production
Specifications
Brand Name :
Zhongshi
Model Number :
Tubing pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
50~60 workdays
Packaging Details :
Standard exported packing
Pump configuration :
Inserted pump
Basic model :
RH and RW
Application :
Oil production
Feature :
Double valve
Barrel coating :
Chrome plated
Plunger coating :
Spray metal
Description

Subsurface Sucker Rod Pump Manufacturer With Long History

Subsurface sucker rod pump description:

For the deep well, Puyang Zhongshi researched and develop the suspension pump. This pump barrel uses a suspension structure, thus it improves the load bearing structure and makes the pump work in the deep well. The setting depth of pump could be 500-1500 meters deep.

This pump has the following characteristics: to prevent bending, the pump uses the gap bridge structure, the barrel is suspended in the outer section and does not bear any pressure thus, not easy to bend.

The space between the plunger and barrel reduces eccentric wear thus, extended the service life and guarantee improved pump efficiency. To prevent loss, the related eccentric distance ε=0. This eccentric distance between barrel and plunger reduce pump loss. This pump is suitable for the deep wells, which where one needs to hang more tail pipes.

Features


1. Suspension structure for pump barrel
2. Operation is simple

THM tubing pump API parameters:

THM model Pump size(in) Barrel length(ft) Plunger length(ft) stroke length(ft)

Tubing size

EUE(in)

 Sucker rod size
20-175THM Ø44.45 7-34 1-26 4-29 2 3/8"

5/8"

3/4"

1"
25-225THM Ø57.15 2 7/8"
30-275THM Ø69.85 3 1/2"
40-375THM Ø95.25 4 1/2"

Pump delivery photo:

Subsurface Inserted Sucker Rod Pump Double valve For Oil production
