Largest Model 30-250 Dia 63.5mm Rod Pump Oil And Gas Thin Wall
Largest Model 30-250 Dia 63.5mm Rod Pump Oil And Gas Thin Wall
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
seating assembly :
Cup seating or mechanical seating
Location of seating assembly :
Top or bottom
Barrel type :
Thin-walled barrel
Barrel coating :
Chrome plated
Model :
RW series
Standard :
API 11AX
Description

Largest Model 30-250 Thin Wall Sucker Rod Pump

30-250 Thin-walled Sucker Rod Pump Description

Thin wall series rod pump has four groups: RWAC, RWBC, RWAM, RWBM. Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API rod pumps) , seating nipple is connected on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work. If the pump appears quality problem, just put the whole pump forward well through the sucker rod string together to avoid putting forward the tubing string

Technical parameter list:

Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
30-250RWAM Ø63.5 2.1-10 0.3-8.0 1.2-9.0 / 3-1/2”
30-250RWBM
30-250RWAC Ø63.5 3-1/2"
30-250RWBC

Features


1. Largest model
2. Mechanical seating or cup seating, can be available on demand
3. Seating location: top seating; bottom seating

Mechanical Propertie

Cup seating or mechanical seating sucker rod pump is suitable for low temperature of oil well and deviated well drilling. Easy to operate, economical and practical, it can reduce oil field operation cost by more than 50%.
