25-175-RHAM 31.75 Inch Sinker Bar Rod Pump Chrome Plated
25-175-RHAM 31.75 Inch Sinker Bar Rod Pump Chrome Plated
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Type1 :
mechanical seating
Type2 :
heavy walled
Seating loacation :
Top
Barrel coating :
chrome plated
Barrel type :
heavy-walled barrel
API certificate :
API 11AX-0061
Description

25-175-RHAM Mechanical Seating Sucker Rod Pump

Mechanical Seating Sucker Rod Pump Description

The complete pump designation of an API pump adds dimensional diameters and lengths to the letter designations. This has been modified in the latest revision to incorporate all approved sizes and barrel types along with separating the extensions into the top and bottom lengths, if required. The complete API designation includes the following:

  • Nominal tubing size (from 1.9- to 4.5-in. OD) - represented with 2 digits
  • Basic bore diameter (from 1.0625 to 3.75 in.) - represented with 3 digits
  • Type of pump (rod or tubing) - R or T to indicate type
  • Type of barrel (heavy, thin, or X type) - single alpha character to represent the barrel type
  • Seating-assembly location (top or bottom) - A (for top), B (for bottom), or T (for bottom, traveling barel)
  • Type of seating assembly (cup or mechanical) - C or M to indicate type
  • Barrel length (ft) - single digit length
  • Nominal plunger length (ft.) - single digit length
  • Length (in.) of upper extension (if required)- single digit length
  • Length (in.) of lower extension (if required)- single digit length


Technical parameter list:

Specification Pump diameter

Barrel length

(ft)

Plunger length

(ft)

Stroke length

(ft)

Extension length

(ft)

Tubing size

EUE/NUE

Sucker rod

size
15-106RHBM Ø26.99

2.1-10

0.3-8

1.2-9

0.3-2.4

 1.9”

5/8” 3/4”
15-106RHBC
20-125RHAM Ø31.75 2-3/8”
20-125RHAC
20-125RHBM
20-125RHBC
20-125RHBM/AC
25-150RHAM Ø38.10 2-7/8”
25-150RHAC
25-150RHBM
25-150RHBC
25-150RHBM/AC
25-175RHAM Ø44.45
25-175RHAC
25-175RHBM
25-175RHBC
25-175RHBM/AC
30-225RHAM Ø57.15 3-1/2”
30-225RHAC
30-225RHBM
30-225RHBC
30-225RHBM/AC


Pump components

There are seven major components for downhole rod pumps: standing and traveling valves, plunger, barrel, seating assembly, pull tube or valve rod (for insert pump), and the fittings that hold the assembled pump together.

25-175-RHAM 31.75 Inch Sinker Bar Rod Pump Chrome Plated
