API 11AX Series Sucker Rod Pump Downhole Pumps Oil And Gas
API 11AX Series Sucker Rod Pump Downhole Pumps Oil And Gas
Specifications
Brand Name :
Zhongshi
Model Number :
Sucker rod pump
Certification :
API, ISO, QHSE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union, D/A
Supply Ability :
1000 SETS/MONTH
Delivery Time :
10~15 workdays
Packaging Details :
Standard exported packing
Barrel type :
Thin wall & heavy wall
Location of seating assembly :
Top or bottom
Barrel coating :
Chrome plated as usual
Model :
RH series and RW series
Plunger steel :
45# steel
API type :
11AX
Description

Oil Well Down Hole API 11AX Series Sucker Rod Pump

Down Hole Sucker Rod Pump Description

A Sucker Rod Pump is an artificial pump system used to connect the downhole pump assembly with the surface components that facilitate a pumping motion. This pump system uses different types of components that generate reciprocating motions which make it easy to lift fluids from bottom to the surface in a vertical movement. It is powered by a motor that causes the plunger to work in two strokes, i.e., up and down.

The main components of a sucker rod pump are standing and traveling valves, plunger, barrel, seating assembly, pull tube or valve rod.

Technical parameter list:

Model Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
25-175RWAM Ø50.8 2.1-10 0.3-8.0 1.2-9.0 / 3-1/2"
25-175RWAC
30-225RWBM Ø63.5
30-225RWBC

Features


1. Sucker rod type downhole pump, not tubing pump

2. Mechanical seating and cup seating
3. Heavy wall barrel and thin wall barrel

Mechanical Propertie

Heaby wall barrel pump is stronger than the thin wall barrel pump
