F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
Specifications
Place of Origin :
China
Brand Name :
SUCE
Model Number :
BD332
Packaging Details :
Standard exporting package
Supply Ability :
50000Piece/month
Price :
$1599.00 - $1,699.00/Pieces
Certification :
CE,ISO13485
MOQ :
1pc
Payment Terms :
T/T, Western Union,Payoneer
Delivery Time :
about 10 days
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Online technical support
Material :
Metal, Plastic
Shelf Life :
1years
Quality Certification :
ce
Instrument classification :
Class I
Safety standard :
GB15979-2002
Product name :
Fetal monitor
Standard Parameters :
TOCO,FHR,FM
Optional parameters :
twin montiroing,FAS,touch screen ,trolley
FHR Working frequency :
1.0MHz
TOCO Measurement Range: :
0-100 units
Measurement :
26.0*40.0*42.0cm
Gross weight :
9.5kg
Alarm :
Available
Display :
12 inch TFT
Language :
Chinese,Turkey,Spain,Poland,French,Portuguese,German,Russian
Description
Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
Product Description
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332

Introduction


This series is a lightweight, compact fetal and maternal monitor, it can meet the need of whole stages of labor (including antepartum and intrapartum monitoring for fetus and mother),It also can be connected to the obstetrical central station. Features: 12 Crystal IPX1 waterproof Probe Built-in large capability rechargeable lithium-ion battery Built-in Z-fold paper thermal printer with adjustable tracing speed Built-in CTG analysis system Multiple display interfaces can be easily switched Monitor the maternal and fetal parameters simultaneously TWIN monitoring function & clinical event mark function CTG data storage & review for 120h Manual/automatic FM measurement Support connecting to central monitoring system Wired/ wireless (optional) connections
Standerd parameters:
TOCO,FHR,FM
Option:
twin montiroing,FAS(Fetal acoustic simulator)
FHR
Transducer: Multi-crystals, wide wave beam, pulsed-wave working method, high sensitivity
Strength: < 5mW/cm2
RESP
Working Frequency: 1.0MHz
Signal Processing: Special DSP system and modern recognition
Alarm Range: High Limit: 160, 170, 180, 190 bpmSpO2
Measurement Range:50～240bpm
Alarm Range: High Limit: 160, 170, 180, 190 bpm Low Limit: 90, 100, 110, 120 bpm
NIBP
Maximum Audio Output Power: 1.5 Watt
TOCO
Measurement Range: 0-100 units
Display
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
Gel
Viscous aqueous non-sensitizing, hypo-allergenic and non-irritating to skin. Bacteriostat (not sterile)
Size and Weight:
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332

Recorder - Recording speed: Real-time recording : 1cm/min, 2cm/min, 3cm/min Review of fast recording: up to 13mm/s - Paper type: 152 mm Z-folded thermosensitive printing paper FHR - Measurement method: Ultrasound Pulsed Doppler - Ultrasonic intensity: < 5mW/cm2 - Ultrasonic frequency: 1.0MHz, deviation less than ±10％ - FHR Measurement Range: 50bpm ~ 210bpm - Resolution: 1bpm - Accuracy: ±2bpm - Output beam intensity(Iob): <20mW/cm2 TOCO - Measurement method: Strain Gauge Sensor Element - Measurement range: 0~100 units (relative to %) - Resolution: 1% (1 unit) - Nonlinear accuracy: ≤ ±10% - TOCO baseline: 0, 5, 10, 15, 20 ,optional

FM - Measurement method: Doppler ultrasound - FM intensity measurement range: 0-40 (%) relative range - Resolution: 1％ - Model: Auto/Manual NIBP - Measurement way: Automatic oscillometry - Measurement mode: Manual , Auto - Intervals for Auto measurement time: 3 min, 5 min, 10 min, 15 min, 30 min, 60 min, 90min, 2h, 4h - Measurement kinds(Adult): Sys, Dia, Map - Measurement range (mmHg): SpO2 - Measurement range: 0% to 100% - Alarm range: High/low limit: 85% to 100% - Resolution: 1% - Accuracy: 70% to 100%: ± 2% 35% to 69%: ±3% 0% to 34%: undefined
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
PR - Measurement range: 20bpm to 250bpm - Alarm range: High/low limit: 0bpm to 300bpm - Resolution: 1 bpm - Accuracy: ±1% or ± 1
bpm - Data update period: 12s
Details Images
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
F50 Waterproof ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM BD332
