Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Specifications
Place of Origin :
China
Brand Name :
SUCE
Model Number :
OEM
Packaging Details :
Standard export packing
Supply Ability :
50000Pieces/month
Price :
$1,499.00 - $1,699.00/Pieces
Certification :
CE,ISO13485
MOQ :
1pc
Payment Terms :
T/T, Western Union,Payoneer
Delivery Time :
about 10 days
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Online technical support
Material :
Metal, Plastic
Shelf Life :
1years
Quality Certification :
ce
Instrument classification :
Class I
Safety standard :
GB15979-2002
Product name :
Maternal Fetal monitor
Standard Parameters :
TOCO,FHR,FM
Optional parameters :
twin montiroing,FAS,touch screen ,trolley
FHR Working frequency :
1.0MHz
TOCO Measurement Range: :
0-100 units
Measurement :
26.0*40.0*42.0cm
Gross weight :
9.5kg
Alarm :
Available
Display :
10.4 inch TFT Colour
Language :
Chinese,Turkey,Spain,Poland,French,Portuguese,German,Russian
Port :
guangzhou
Description
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM
Product Description
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22

Introduction

The MP22 Series high-tech fetal monitor offers a reliable, high-performance solution for fetal monitoring needs in doctors’ practices, clinics and hospitals, from pre-natal check-ups to antepartum monitoring of high-risk pregnancies.

An optional USB Mouse/Keyboard control eases navigation and data entry.

An optional Non-Stress Test (NST) report software eases documentation in antepartum monitoring.
Standerd parameters:
TOCO,FHR,FM
Option:
twin montiroing,FAS(Fetal acoustic simulator)
FHR
Transducer: Multi-crystals, wide wave beam, pulsed-wave working method, high sensitivity
Strength: < 5mW/cm2
RESP
Working Frequency: 1.0MHz
Signal Processing: Special DSP system and modern recognition
Alarm Range: High Limit: 160, 170, 180, 190 bpmSpO2
Measurement Range:50～240bpm
Alarm Range: High Limit: 160, 170, 180, 190 bpm Low Limit: 90, 100, 110, 120 bpm
NIBP
Maximum Audio Output Power: 1.5 Watt
TOCO
Measurement Range: 0-100 units
Display
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
Gel
Viscous aqueous non-sensitizing, hypo-allergenic and non-irritating to skin. Bacteriostat (not sterile)
Size and Weight:
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22

Recorder - Recording speed: Real-time recording : 1cm/min, 2cm/min, 3cm/min Review of fast recording: up to 13mm/s - Paper type: 152 mm Z-folded thermosensitive printing paper FHR - Measurement method: Ultrasound Pulsed Doppler - Ultrasonic intensity: < 5mW/cm2 - Ultrasonic frequency: 1.0MHz, deviation less than ±10％ - FHR Measurement Range: 50bpm ~ 210bpm - Resolution: 1bpm - Accuracy: ±2bpm - Output beam intensity(Iob): <20mW/cm2 TOCO - Measurement method: Strain Gauge Sensor Element - Measurement range: 0~100 units (relative to %) - Resolution: 1% (1 unit) - Nonlinear accuracy: ≤ ±10% - TOCO baseline: 0, 5, 10, 15, 20 ,optional

FM - Measurement method: Doppler ultrasound - FM intensity measurement range: 0-40 (%) relative range - Resolution: 1％ - Model: Auto/Manual NIBP - Measurement way: Automatic oscillometry - Measurement mode: Manual , Auto - Intervals for Auto measurement time: 3 min, 5 min, 10 min, 15 min, 30 min, 60 min, 90min, 2h, 4h - Measurement kinds(Adult): Sys, Dia, Map - Measurement range (mmHg): SpO2 - Measurement range: 0% to 100% - Alarm range: High/low limit: 85% to 100% - Resolution: 1% - Accuracy: 70% to 100%: ± 2% 35% to 69%: ±3% 0% to 34%: undefined
Details Images
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
