Features:
Accurately measuring the low-degree lens below +-0.12D.
Measuring the colored lens with 10% transmittance.
Displaying the PH value in screen.
Measuring the progressive lens accurately and quickly.
Optionally installing PD measuring instrument, UV measuring instrument and thermal printer.
User friendly interface with easy operation; fast measurement, high accuracy and good repetition.
Main Technology Parameters:
| SPHERE | -25.00D-+25.OOD | |
| Contact lens | -25.00D-+25. ODD (BC=6.00-9.00) (0.01D/0.12D/0.25DSTEPS) |
|
| CYLINDER | 0.00D-±10.00D(-,MIX,+} (0.01D/0.12D/0.25DSTEPS) |
|
| AXIS | 0°-180°(1°STEPS) | |
| ADD | 0.00D~+-10.00D (Add and Ad2) 0.00D~+-10.00D (Add and Ad2) |
|
| PRISM | 0.00-10.00 (horizantal,vertical) (0.01D/0.12D/0.25DSTEPS) |
|
| PD measuring range | 80mm | |
| Diameter for sphere | 20MM-Φ100MM | |
| Diameter for contact lens | 5MM | |
| UV | >100% (+_15.00D~+-25.00D, >20%) | |
| Color LCD display | 5.7inches TFT LCD Monitor | |
| Printer | Thermal Printer | |
| DATD INTERFAGE | RS-232 | |
| Power supply | AC100(+-10%) -240(+-10%)V 50/60HZ 40VA | |
| Dimensions | 190(W) x 205(D)x418 (D)MM | |
| Weight | 4.5 KG | |
