Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency
Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency
Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency
Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency
Specifications
Brand Name :
APK
Model Number :
submersible pump
Certification :
ISO9001;ISO14001;CE,BV; TUV; SGS; five stars after-sale service
Place of Origin :
Henan, China
MOQ :
1 piece
Price :
Please feel free to contact us
Payment Terms :
T/T, Western Union, L/C, MoneyGram, D/P, D/A
Supply Ability :
8578 pieces per month
Delivery Time :
7-15 working days after payment confirmation
Packaging Details :
Deep well submersible pump is packed with wooden case or 20 inch container.
Power :
90kw 100kw submersible pump
Horsepower :
120hp 135hp submersible pump
Diameter :
10 12 inch well submersible pump
Flow :
58m3/h-1200m3/h
Head :
12m-343m
Voltage :
380v/440v/460v/480v/600v/660v or as per request
Frequency :
3 Phase 50hz/60hz
Material :
cast iron/stainless steel 304/316/316l/duplex stainless/904l
Features :
High flow; high head; anti-corrosive
Warranty :
24 months
Description

90kw 120hp 100kw 135 hp 100m3/h 200m3/h Vertical Pumps Electric Deep Well Water Submersible Pump

90kw 100kw submersible pump parameters:

(cast iron/stainless steel 304/316/316l/duplex stainless/super stainless steel/ss904l and 380v/440v/480v/600v/ 660v/1140v.

Diameter Model Motor Power Capacity Range Head Range
Inch (") QJ Series kw hp m3/h m
10" 250QJ63-300/15 90 120 58-68 205-343
10" 250QJ80-240/12 90 120 74-86 204-276
10" 250QJ80-260/13 100 135 74-86 220-280
10" 250QJ100-198/11 90 120 80-120 170-231
10" 250QJ100-216/12 100 135 80-120 190-252
10" 250QJ125-160/10 90 120 116-134 136-184
10" 250QJ125-176/11 100 135 116-134 150-202
10" 250QJ140-135/9 90 120 130-145 114-156
10" 250QJ140-150/10 100 135 130-150 130-171
10" 250QJ160-120/8 90 120 148-172 102-138
10" 250QJ160-135/9 100 135 148-172 115-155
12" 300QJ200-100/5 90 120 186-214 85-115
12" 300QJ240-110/5 100 135 223-257 95-125
14" 350QJ250-75/3 90 120 233-267 72-78
16" 400QJ500-40/1 90 120 460-540 38-42
18" 450QJ1000-16/1 90 120 900-1200 12-20
20" 500QJ640-28/1 90 120 600-680 26-30

Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency

90kw 120hp 100kw 135hp well submersible water pump overview :
QJ deep well submersible pump is widely used in farmland irrigation, spray irrigation, water supply system for industrial
buildings and civil buildings, water distribution system in mountain areas, low-lying areas and dunes, water supply and water drainage system for mines in urban or rural districts, and other water conservancy facilities.

90kw 100kw well submersible water pump performance range:
* Diameter: 10 12 14 16 18 20 inch submersible pump
* Flow: 58-1200m3/h
* Head: 12-343m
* Power: 90kw 100kw 120 hp 135 hp submersible pump
* Voltage: 380v/440v/460v/480v/600v/660v/1140v or as per request
* Frequency: 3 phase 50hz/60hz
* Material: cast iron/stainless steel 304/316/316l/duplex stainless/super stainless steel/904l

Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency

We also manufacture water pump accessories, such as pump control cabinet, frequency converter, cable, valve, etc.

Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency

Shenlong (APK) pump factory mainly manufactures submersible pump and centrifugal pump, drawing sea water, salt water, clean water, sewage water, hot water. Vertical or horizontal install.

Electric Deep Well Submersible Pump Anti Corrosive 3 Phase 50hz / 60hz Frequency
