Specifications
Brand Name :
HCGG
Model Number :
SSPH001
Certification :
CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001
Place of Origin :
Henan,China
MOQ :
50 square meters
Price :
USD20-100 Square Meter/Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
50000 Tons/year
Delivery Time :
2０-５0days
Main Structurel Material :
Q355B/ASTM A572 Gr.50/EN S355/JIS SM490
Secondary Structurel Material :
Q235B / ASTM A36/ EN S235JR / JIS SS400
Other Material :
Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570
Customization :
Style,size,Color,Material
Project Solution Capability :
CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply
After-sale Service :
Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support
Column and Beam :
Welded H-section/Hot-rolled H-beam/Box column
Purlin :
C.Z Shape Steel Channel
Roof and Wall panel :
EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized/
Window :
Aluminum alloy / PVC /Industrial louver window
Door :
Sliding/Rolling shutter/Hinged steel/Customized steel door
Surface treatment :
Hot-dip galvanized Zinc-rich primer + top coat Anti-corrosion coating
Service Life :
20-50 Years
Life Span :
More Than 50 Years
Description
Customizable Size Automatic Poultry Farm Equipment Structure
Steel-structured poultry houses are prefabricated, modular farming facilities designed for modern large-scale poultry farming. Using Q235/Q355 high-strength steel as the core material with portal steel frame construction, they represent an upgraded alternative to traditional brick-and-wood or concrete poultry houses.
Key Features
  • Main structure composed of steel columns, beams, and purlins with composite sandwich panel enclosure
  • Corrosion-resistant treatment for high humidity environments with service life exceeding 30 years
  • Large-space design without central columns to accommodate automated farming equipment
  • Factory prefabrication and on-site bolt assembly for efficient construction
  • Thermal insulation properties with easy cleaning and disinfection capabilities
  • Stabilized internal environment reducing disease risks in intensive poultry farming
Customizable Size Poultry Farm Building Structure Thermal Insulation Large Space Design
Product Specifications & Parameters
Main Load-Bearing Structure
Core framework designed for maximum stability and load-bearing capacity:
  • Steel Columns and Beams: Q235/Q355 H-beams, portal frame, single span 15-40 meters without central columns
  • Purlins and Tie Rods: C/Z-shaped cold-formed steel supporting enclosure panels with reinforced joints
  • Foundation Connectors: Anchor bolts and washers suitable for high-humidity environments
Protective Enclosure System
Temperature-controlled and sealed enclosure combining insulation and waterproofing:
  • Wall and Roof Panels: 50-100mm composite sandwich panels providing insulation and fireproofing
  • Roof Accessories: Double-slope roof trusses, gutters, drainage pipes with optional FRP skylights
  • Doors, Windows and Ventilation: Insulated doors and windows with reserved ventilation locations
Auxiliary Functional Components
  • Connectors: High-strength bolts and rubber strips for efficient sealing
  • Aquaculture Accessories: Reserved equipment mounting locations with zoning capability
  • Corrosion-resistant Components: All steel components galvanized for ammonia and humidity resistance
Technical Specifications Table
Structure Part Specification
Main Structure Frame Column and Beam Q235,355B H section steel
Surface Processing Coating or Galvanized -
Purlin C/Z Purlin Size from C120-C320,Z100~Z300
Angle Brace L-Steel Q235B
Cross Brace/X Brace Round Pipe Q235B
Tie Bar Round Bar Q235B
Roof System Roofing Material Sandwich Panel, Steel Sheet
Skylight Panel FRP 1.2mm
Gutter Steel Gutter Galvanized/Coated 2.0mm-3.0mm
Rainspout/Down Pipe PVC Pipe -
Wall System Wall Material Sandwich Panel, Steel Sheet
Accessories Sealant, Self-tapping Screw etc -
Edge Cover Color Steel -
Ventilator Unpowered Axial-Flow Ventilator or Monitor Roof -
Door Electric Rolling Door/Sliding Door/Access Side Door -
Window Aluminum/PVC -
Product Applications
  • Compatible with all poultry breeds and complete breeding cycles
  • Adaptable to various farming scales with customization support
  • Suitable for standardized farming projects of all types
  • Designed for high-risk disease prevention and intelligent farming systems
  • Supports green and distinctive farming models
  • Can serve as emergency temporary farming sheds
  • Optimized for multi-layer cage rearing to improve efficiency
  • Suitable for low-impact farming in urban and suburban areas
  • Adaptable to complex climate regions
  • Contributes to rural revitalization and poverty alleviation programs
Company Profile
HCGG operates a 30,000 square meter production base with integrated design, manufacturing, and export capabilities. With over 200 employees and four light and heavy steel structure production lines, we maintain an annual production capacity exceeding 50,000 tons, ensuring reliable delivery for projects of all sizes.
Main Products
Steel structural components, H-beams, box girders, box columns, cross columns, round tubular columns, various truss structures, steel plate walls, and custom fabrications.
After-Sales Service
Our professional service team provides installation guidance, regular customer follow-ups, and remote or on-site technical support. All products are manufactured strictly according to approved drawings, with full production transparency for customer review.
Customizable Size Poultry Farm Building Structure Thermal Insulation Large Space Design Customizable Size Poultry Farm Building Structure Thermal Insulation Large Space Design Customizable Size Poultry Farm Building Structure Thermal Insulation Large Space Design Customizable Size Poultry Farm Building Structure Thermal Insulation Large Space Design
Frequently Asked Questions
Do you provide installation services?
We provide detailed installation drawings and videos free of charge. If needed, we can arrange for an engineer to provide on-site installation guidance and technical support.
What is your delivery time?
Delivery time depends on project size, product specifications, and order quantity. Generally, production is completed within 20-35 days after receiving prepayment. Large projects can be negotiated separately.
How can I get a project quotation?
We provide free, fast, customized quotations. With drawings: We can provide a quotation directly based on the drawings. Without drawings: Please provide building length, width, eaves height, and local climate conditions for a reasonable quotation and corresponding solutions.
What are your payment terms?
30% deposit before production, with balance due before shipment. Supported payment methods: T/T, Western Union, Alibaba Pay.
