Specifications
Window :
Aluminum Alloy / PVC /Industrial Louver Window
Door :
Sliding/Rolling Shutter/Hinged Steel/Customized Steel Door
After-Sale Service :
Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support
Certification :
CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001
Brand Name :
HCGG
MOQ :
100 square meters
Secondary Structurel Material :
Q235B / ASTM A36/ EN S235JR / JIS SS400
Model Number :
ISB001
Surface Treatment :
Hot-dip Galvanized Zinc-rich Primer + Top Coat Anti-corrosion Coating
Price :
USD25-70 Square Meter/Negotiable
Roof And Wall Panel :
EPS/Rock Wool/PU / PIR Sandwich Panel Corrugated/Trapezoidal Steel Sheet/Customized
Service Life :
20-50 Years
Main Structurel Material :
Q355B/ASTM A572 Gr.50/EN S355/JIS SM490
Seismic and Wind Resistance Rating :
Designed according to local seismic codes/Wind：0.3-1.1 KN/㎡/81-150 mph
Customization :
Style / Size (Span, Height, Length) /Color / Material / Crane Capacity
Purlin :
C.Z Shape Steel Channel
Column And Beam :
Welded H-section/Hot-rolled H-beam/Box Column
Other Material :
Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570
Service Life Time :
50+ Years
Delivery Time :
20-50days
Project Solution Capability :
CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply
Life Span :
More Than 50 Years
Place of Origin :
Henan,China
Supply Ability :
50000 Tons/year
Roof and Wall panel :
EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized
Description
Large-Span Industrial Steel Structures
High-strength steel structures manufactured to CE, ISO, and SGS standards for industrial facilities requiring large clear spans.
Product Overview
Large-span industrial plant steel structures are prefabricated building systems designed for high-strength, long-span industrial facilities. Utilizing standardized design, factory fabrication, and on-site assembly, these structures provide the most cost-effective and efficient solution for modern factories, warehouses, workshops, and logistics centers.
Structural Components
  • Main Frame: H-beams and columns
  • Secondary Structure: Purlins, wall beams, bracing system
  • Enclosure: Roof/wall panels, insulation layer, skylights
  • Accessories: Doors, windows, crane beams, ventilation system
Span Classification
Single-story industrial buildings with clear spans ≥30m and minimal central columns are classified as large-span steel structures:
  • Medium to Large Spans (30–60m): Portal frames and ordinary steel trusses
  • Large Spans (60–120m): Space trusses, space frames, and reticulated shells
  • Extra-Large Spans (>120m): Prestressed steel structures, suspension cables, and tensioned beams
Typical column spacing ranges from 9–24m, suitable for heavy production, warehousing, logistics, aircraft hangars, and other applications requiring continuous large spaces.
Technical Specifications
Parameter Specification
Structure Type Portal Frame / Steel Truss / Space Grid / String Beam
Clear Span 30m – 120m+
Building Height 6m – 20m
Column Spacing 6m, 9m, 12m, 15m, 18m, 24m
Building Length Customized (Unlimited)
Design Service Life 50 Years
Seismic Intensity Grade 6 – 9
Wind & Snow Load According to local building code
Main Steel Material Q235B, Q355B, Q355C High-Strength Steel
Fabrication Factory prefabricated, CNC cutting, automatic welding
Connection High-strength bolts + site welding
Roof Load 0.3 – 0.8 kN/㎡
Wall Load 0.3 – 0.55 kN/㎡
Crane Capacity 5t – 50t (optional)
Roof Panel EPS / Rockwool / PU Sandwich Panel, Corrugated Steel Sheet
Roof Thickness 50 – 200 mm
Wall Panel Rockwool Sandwich Panel, Color Steel Sheet
Wall Thickness 50 – 150 mm
Thermal Conductivity ≤ 0.04 W/(m·K)
Doors & Windows Industrial sliding door, rolling door, aluminum window
Daylighting Skylight panel / roof window (optional)
Performance Advantages
  • Large column-free space with high utilization rate
  • High factory prefabrication rate with short construction cycle
  • Lightweight design reducing foundation costs
  • Excellent earthquake and wind resistance with superior durability
  • Expandable, relocatable, and fully recyclable
  • Suitable for overseas modular transportation and installation
High Strength Q355B Q235B Industrial Steel Structure Building Bolt Assembled SGS Standard High Strength Q355B Q235B Industrial Steel Structure Building Bolt Assembled SGS Standard High Strength Q355B Q235B Industrial Steel Structure Building Bolt Assembled SGS Standard
Applications
Primary Applications:
  • Large factories and heavy industrial workshops
  • Logistics warehouses and cold chain storage facilities
  • Aircraft hangars and large public venues
  • Overseas industrial parks and EPC projects
Typical Use Cases:
  • Large industrial workshops
  • Warehouses and logistics centers
  • Assembly plants
  • Machinery plants
  • Supermarkets and exhibition halls
  • Aircraft hangars and large public facilities
