Specifications
Brand Name :
Suntech
Model Number :
SX4-V1
Certification :
ISO9001
Place of Origin :
Ningbo, China
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
1000 PCS/Month
Delivery Time :
7-15days
Packaging Details :
Wooden Case
Name :
Tractor-drawn Winch
Item No. :
08126
Traction force :
20-40KN
Traction speed :
11-38M/Min
Bottom of groove diameter :
300mm
Number of groove :
6
Weight :
1740KG
Outline size :
2900x14000x1440mm
Warranty :
1 year
Description

Tractor-drawn Winch Transmission Line Walking Tractor Drawn Winch Machine

Suntech Power is a Professional manufacturer of transmission line stringing tools and equipments in Ningbo,China.

Such as conductor stringing blocks,cable roller,hoisting tackles,pulley blocks,conductor grippers,cable reel stand,gin poles,inspection trolleys,hydraulic puller tensioner,conductor compressors,cable pulling winch,anti twisting wire steel rope,etc.

Application

Fast Speed Double Drum Winch Tractor For Pulling and Lifting During Tower Erection is applicable to pull no-twist wire rope.Suitable for the construction of the tower line,traction line,tight line operation,laying cable.

Features

Four gear,forward gear and reverse gear

Double drum,seven groove,protect the wire rope

speedy and convenient

The grinding of walking tractor is reformed from 12 type walking tractor.

It is made of four-wheel drive 304 type tractors. Can use a two-wheel drive 300 tractor(Item No. 08127)

Specifications:

Item number

08126

Power

22KW

 Model SX4-V1
Gear Ⅰ Ⅱ

Ⅲ

 reversalⅠ
Traction force(KN) 40 30

20

 -
Traction speed(M/MIN) 12 21

38

 11
bottom of groove diameter Φ300mm
Number of groove 6
Weight(KG) 1740kg
outline size 2900x14000x1440mm
