Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Portable Hydraulic Wire Rope Cutter Compact Design For On Site Construction Use​
Specifications
Brand Name :
Suntech
Model Number :
QY-30
Certification :
ISO
Place of Origin :
Ningbo
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
2000PCS/Month
Delivery Time :
7-15days
Packaging Details :
Plywood Case
Name :
Hydraulic Steel Wire Rope Cutter
Item No. :
16275/16275A
Model :
QY30-QY48
Diameter of applicable :
10-48mm
Maximum cutting force :
75-200KN
Manual force on handle :
<25-<39KGF
Weight :
14-30KG
Warranty :
1 year
Description

​​Hydraulic Steel Wire Rope Cutter - Heavy-Duty Industrial Tool for 10mm-50mm Diameter Cables​


The ​​Hydraulic Steel Wire Rope Cutter​​ is a ​​professional-grade industrial tool​​ designed for ​​clean, precise cutting of steel cables, wire ropes, and rigging systems​​. With an ​​ultra-powerful 30-ton hydraulic system​​, it effortlessly cuts through ​​5mm to 50mm diameter steel wires​​ without causing fraying or deformation. Unlike manual cutters or angle grinders, this tool ​​maintains cable integrity​​ and improves work efficiency by ​​90%​​.


​​Key Features:​​
✔ ​​Heavy-Duty Cutting Capacity​​ - Handles ​​up to 50mm diameter​​ steel wire ropes
✔ ​​Tungsten Carbide Blades (HRC 70+)​​ - Ultra-sharp and long-lasting for ​​15,000+ cuts​​
✔ ​​Zero Energy Dependency​​ - Fully hydraulic operation, no electricity required
✔ ​​Safety Lock Mechanism​​ - Dual-hand operation prevents accidental activation
✔ ​​Portable & Durable​​ - Weighs only ​​15kg​​ with reinforced steel frame


​​Performance Benefits:​​

  • ​​Cuts 20mm steel rope in 3 seconds​​ - 10X faster than manual tools
  • ​​Clean, burr-free cuts​​ - Preserves cable strength for critical applications
  • ​​Low maintenance​​ - Self-lubricating system requires servicing every ​​10,000 cuts​​

​​Technical Specifications:​​

  • ​​Model:​​ QY-30
  • ​​Max Cutting Diameter:​​ 50mm
  • ​​Blade Material:​​ Tungsten carbide-coated
  • ​​Operating Temperature:​​ -30°C to 60°C
  • ​​Compliance:​​ ISO 9001, CE, DNV-GL
  • ​​Warranty:​​ 1 years


​​Ideal Applications:​​

  • Marine and offshore rigging
  • Mining and construction cable cutting
  • Elevator and crane maintenance
  • Power transmission line installation
Item No. Model Diameter of applicable(MM) Maximum cutting force(KN) manual force(KGF) Weight(KG)
16275 QY-30 Φ10-30 75 <=25 14
16275A QY-48 Φ10-48 200 <=39 30
