SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
SZ3A Three-Conductor Board with 100-180kN Rated Load, Anodized Aluminum Body, and Pre-Assembled Modules for EHV Stringing Jobs
Specifications
Model Number :
SZ3A
Packaging Details :
Plywood Case
MOQ :
1 PCS
Delivery Time :
3-7days
Price :
Negotiable
Rated Load :
100-180KN
Payment Terms :
L/C,T/T
Model :
SZ3A
Supply Ability :
500 PCS/Month
Name :
Head Boards for Three Bundle Conductors
Width :
100-110mm
Brand Name :
Suntech
Certification :
ISO9001
Place of Origin :
Ningbo
Description

SZ3A Three-Conductor Board for 100-180kN EHV Stringing Jobs


Product Overview

Pull three sub-conductors in one go and the risk is not the load — it is geometry. If the three lines lose their triangular pattern mid-span, gusts make them whip into each other and the pull stops for repairs. The SZ3A board fixes the trio in a rigid triangle for the entire run, so crews can hold 100-180kN loads with the layout unchanged from drum to tower. Its anodized aluminum body resists UV, rain and salt spray; reinforced stress points absorb the shock of heavy pulls; and color-coded, pre-assembled modules cut rigging time. Built for EHV and UHV sites, it is the steady hand a three-line pull needs.

Technical Specifications

Item No.

Model

Rated Load (KN)

Applicable Sheave Width (mm)

Weight (kg)

Steel Rope Length (m)

17228

SZ3A-10

100

100

114

1*30+1*15

17229

SZ3A-13

130

110

130

17230

SZ3A-18

180

110

142

Applications

· Pulling three sub-conductors at once on EHV/UHV lines

· Holding a fixed triangular layout between adjacent lines

· Preventing wind-driven whipping on long-span pulls

· Rigging large cross-section triple bundles

Product Advantages

· Triangle Held Rigid — the three sub-conductors keep a constant relative angle for the whole pull, so spacing drift never gets a chance.

· Frame Built for the Load — high-grade aluminum plus reinforced stress points copes with 100-180kN working loads across repeated pulls without fatigue.

· Weatherproof Outside — anodized surfaces stand up to UV, rain and salt, keeping the board field-ready season after season.

· Fast on the Tower — color-coded, pre-assembled modules go together quickly; smooth edges and non-conductive options protect insulation.
