100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
Specifications
Brand Name :
JIATUO
Model Number :
JTPP-110
Certification :
CE, ISO
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
50set/month
Delivery Time :
30~55 working days
Packaging Details :
plastic film or other standard package for sea shipping
Name :
PP strapping production line
Raw material :
Polypropylene PP raw material pellets, recycled pellets
Screw design :
Optional
Twin Screw Type :
Co-rotating Parallel Twin-screw
Driven Type :
Electric
Processing type :
Extruding Machine
Automation :
Automatic
Application :
Packaging Strap
Width :
5-19 mm
thickness :
0.3-1.2 mm
Description

100-300m/min line speed 5-19 mm PP strapping production line PP strapping equipment

DESCRIPTION OF PP STRAPPING PRODUCTION LINE

Production speed:

usually 200-300 m/min (high-speed equipment can reach more than 300 meters).

Band width/thickness range: width 5-19mm, thickness 0.3-1.2mm (customizable).

Raw material requirements: PP new material or recycled material.

Power consumption: The whole machine power is about 100kW (depending on the production capacity).

FEATURES

Extrusion----Extrusion capacity can be customized according to customer requirements, and can produce 2-12 strips.

Oven-----Energy-saving and environmentally friendly, constant temperature oven, high output, low power consumption.

Winding machine-----Can be equipped with semi-automatic winding machine & fully automatic winding machine according to customer requirements


EXTRUSION PARAMETERS TABLE

Model PP-2 PP-4 PP-6 PP-8 PP-10 PP-12
Raw material PP polypropylene new material/recycled material
Number of tapes 2 4 6 8 10 12
Width(mm) 5-19 5-19 5-19 5-19 5-19 5-19
Thickness(mm) 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2
Line speed(m/min) ≧260-300
PLC control system PLC PLC PLC PLC PLC PLC
Screw Model 90 110 125 135 135 135
Reducer model 200 220 250 280 280 280
Winding machine Automatic winding machine /Semi-automatic winding machine
Screen Changer Automatic/Manua
Production capacity 24H 2.5-3T 6-7T 8-9T 10-11T 12-13T 13--14T

100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment
Auxiliary Feeding Section:

The PP strapping equipment is equipped with ---- 3 sets of auxiliary feeders,

Can add dyeing masterbatch------- change the color of PP strap

Can add filling masterbatch----- reduce the cost of PP strap by more than 30%

Can add defoaming agent-------- eliminate the moisture of PP raw materials

Applicable to balers:

1. Fully automatic baler

2. High-speed baler

3. Semi-automatic baler

4. Handheld electric baler

5. Manual clamp baler

100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment

100-300 m/min line speed 5-19 mm PP strapping production line PP strapping equipment

FQA:

Q:What is the voltage of PP Strapping Production Line?
A:380V/50HZ, we support customization
Q:Can the PP Strapping Production Line be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP Strapping Production Line?
A:We are from China.
Q:Can PP Strapping Production Line provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP Strapping Production Line stable?
A:We have 30 years of manufacturing experience, and have their own PP strapping equipment plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
