Specifications
Brand Name :
PET plastic steel belt production equipment
Model Number :
JTPET-100
Certification :
IS CEO
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Delivery Time :
50-60days
Packaging Details :
plastic film
Raw material :
PET Bottle Flake Material, 100% Broken Material
Voltage :
380V/50HZ （customized ）
Control System :
PLC Computer Touch Screen
Product Name :
PET Plastic Steel Belt Production Equipment
Winding method :
Manual/automatic
Power :
45KW
Weight :
18000KG
Solid-state relay :
Taiwan Yangming
Metering Pumps :
100 CC
Screen changer :
chemical fiber filter
Description

16mm transparent pet strap manufacturing machine high-speed PET strapping equipment PET production line

Product Description of PET strap manufacturing machine:

pet strap manufacturing machine

Features :

1. Good tensile strength----pet strap manufacturing machine has the tensile strength of steel tape, good ductility, good impact resistance, not easy to break, and ensures the safety of product transportation.
2. Small elongation----Although PET strapping belt is a kind of plastic, its elongation changes very little, and its elongation is only 1/6 of polypropylene. It can maintain tension and make the expansion and contraction amount no longer change after packaging.
3. Strong temperature resistance----Experiments have proved that the melting point of PET strapping belt is about 260℃, and it can be used for a long time at 120℃ without deformation, and has good stability.
4. Good economic benefits----The density of PET strapping belt is 1.30~1.38g/cm3, which is only 1/6 of the density of steel tape (7.8g/cm3), equivalent to the length of 6-ton steel tape, and the price per unit length is relatively low.

16mm transparent pet strap manufacturing machine high-speed PET strapping equipment PET production line

Raw Materials-------
High-end PET strapping can be produced using 100% PET bottle flakes or crushed material.

16mm transparent pet strap manufacturing machine high-speed PET strapping equipment PET production line

PRODUCT DESCRIPTION

Model PET-2 PET-3 PET-4 PET-6 PET-8
Raw materials Bottle flakes/crushed materials
Number of tapes 2 3 4 6 8
Width (mm) 9-32
Thickness (mm) 0.4-1.2
Maximum line speed(m/min) ≧150 ≧150 ≧150 ≧150 ≧150
Screw Model 90 100 125 150 180
Reducer model 200 250 280 315 350
Dehumidifier 1000 1000 2000 3000 3500
Metering Pumps 100CC
Production capacity /24 H 5-6T 7-8T 10-12T 12-15T 18-20T

pet strap manufacturing machine extrusion process:

Horizontal feeder -------mix different PET crushed materials or bottle flakes evenly.

Drying barrel ------ heat the PET raw materials to dry the moisture.

Dehumidifier--------remove the moisture in the PET raw materials.

Extrusion molding-------make the molten PET belt blank pass through the mold to form.

Cooling water tank-------cool the extruded PET belt blank to ensure its molding.

Tractor--------tow the cooled PET strapping belt to maintain a stable production speed.

Stretcher--------stretch the formed PET belt instantly, about 1-10 times

Oven--------heat the strapping belt to improve the toughness of the PET belt.

Embossing machine------emboss the surface of the strapping belt to increase friction and prevent slipping.

Forming oven--------heat and shape again to make the PET belt more standardized.

Rewinder---------roll the strapping belt into a roll for easy storage and transportation.

16mm transparent pet strap manufacturing machine high-speed PET strapping equipment PET production line

FQA:

Q: What is the voltage of the pet strap manufacturing machine ?

A: 380V/50HZ, three-phase (customization supported)

Q: What is the extrusion capacity of the pet strap manufacturing machine?

A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H

Q: What is the producible width of the pet strap manufacturing machine?

A: 9-32mm

Q: Can the pet strap manufacturing machine be customized?

A: Customization supported

Q: Where does the pet strap manufacturing machine come from?

A: China.

Q: What are the certifications for the pet strap manufacturing machine?

A: ISO CEO certification.

Q: What is the minimum order quantity for the pet strap manufacturing machine?

A: 1 set

Q: What is the weight of the pet strap manufacturing machine?

20T, 40GP container * 3PCS
