Specifications
Brand Name :
JIATUO CHINA
Model Number :
JTPET-100
Place of Origin :
CHINA
Certification :
IS CEO
MOQ :
1 SET
Price :
Negotiable
Packaging Details :
plastic film
Delivery Time :
50-60days
Supply Ability :
20Ton /Monthly
Name :
PET Strap Making Machine
Strap Width :
9-32mm
Raw material :
PET bottle flake material
Paper tube size :
¢406*150mm
Inverter :
45KW(INVT)
Extrusion quantity :
4
Strap Core Material :
Paper/Plastic/Aluminum
Strap Tension :
150-850kg
Description

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

PRODUCT DESCRIPTION OF PET STRAP MAKING MACHINE:

This PET Strap Making Machine PET plastic-steel strapping equipment is a specialized production line that converts recycled or virgin polyethylene terephthalate (PET) into high-strength plastic strapping through a process including melting, extrusion, stretching, shaping, and winding. PET plastic-steel strapping is widely used for heavy-duty packaging in industries such as steel, aluminum, papermaking, chemical fiber, and building materials due to its high strength, corrosion resistance, aesthetic appeal, and recyclability

FEATURES:

  • Product Name: PET Strap Making Machine
  • Strap Color: White/Black/Blue/Green Etc.
  • Strap Width: 9-32mm
  • Raw material: PET bottle flake material&100% broken material
  • Strap Core Material: Paper/Plastic/Aluminum
  • Features: Double cylinder/Single cylinder, 100% recycled bottle flakes material

Technical Parameters:

Model

Width

Thickness

Pull

Gross weight

Net weight

Paper core diameter

Length

Other models
PET-0950 9.0mm 0.50mm >150kg 20kg 18.5kg 200/406mm 3400m PET-1610
PET-1050 10.0mm 0.50mm >180kg 20kg 18.5kg 200/406mm 2900m PET-1970
PET-1250 12.0mm 0.50mm >210kg 20kg 18.5kg 200/406mm 2400m PET-1910
PET-1260 12.0mm 0.60mm >220kg 20kg 18.5kg 200/406mm 2000m PET-1912
PET-1360 13.0mm 0.60mm >250kg 20kg 18.5kg 200/406mm 1850m PET-2512
PET-1660 16.0mm 0.60mm >320kg 20kg 18.5kg 200/406mm 1500m PET-3512
PET-1670 16.0mm 0.70mm >370kg 20kg 18.5kg 200/406mm 1300m
PET-1680 16.0mm 0.80mm >450kg 20kg 18.5kg 200/406mm 1200m

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

PET plastic strapping (also known as PET strapping) production equipment is specialized for producing high-strength, environmentally friendly PET plastic strapping. Its key features include:

1. Efficient and Automated Production

Continuous Production------ PET equipment utilizes an integrated process for extrusion, cooling, stretching, shaping, and winding, resulting in a high degree of automation and high production efficiency, making it suitable for large-scale production.

Intelligent Control------- A PLC (Programmable Logic Controller) and touchscreen human-machine interface enable precise control of parameters (such as temperature, tension, and speed), minimizing manual intervention.

Quick Mold Change-------- Some equipment supports quick mold changes, enabling flexible production of plastic strapping in various widths (e.g., 9mm--25mm) and thicknesses. This is convenient and hassle-free.

PET strapping performance characteristics (determined by the production line): PET strapping manufactured on this production line possesses the following superior properties:

High strength---- Tensile strength can reach more than half that of steel strapping, far exceeding PP/plastic strapping.

High toughness------ Excellent impact resistance; not easily broken under sudden force.

Resistant to deformation: Low elongation, maintains tension for a long time, and the packaged items will not loosen for an extended period after packaging.

Good safety------ No steel spikes, does not injure hands, safe for bundling and opening operations.

Aesthetically pleasing and corrosion-resistant----- Smooth surface, clear printing, rust-free, and resistant to high temperatures, cold temperatures, and corrosion from various chemicals.

Recyclable----- Used strapping can be 100% recycled and reused, meeting environmental protection requirements.

Polyester Polyethylene Terephthalate PET Straps Band Production Line Plastic Pet Strap Making Machine,PET plastic steel

FAQ:

Q1: What is the Brand Name of the PET Strap Making Machine?

A1: The Brand Name of the PET Strap Making Machine is JIATUO CHINA.

Q2: What is the Model Number of the PET Strap Making Machine?

A2: The Model Number of the PET Strap Making Machine is JTPET.

Q3: Where is the PET Strap Making Machine made?

A3: The PET Strap Making Machine is made in China.

Q4: What is the Certification for the PET Strap Making Machine?

A4: The Certification for the PET Strap Making Machine is IS CEO.

Q5: What is the Minimum Order Quantity for the PET Strap Making Machine?

A5: The Minimum Order Quantity for the PET Strap Making Machine is 1 SET.
