Specifications
Brand Name :
JIATUO CHINA
Model Number :
JTPP
Certification :
ISO/ CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
L/C,T/T
Delivery Time :
50-60DAYS To be negotiated
Packaging Details :
Plastic film
Plastic Processed :
PP
Screw diameter (mm) :
90/100/110/125/135mm
production capacity :
120-900kgs/H
Warranty :
1 years
Number of extruded strap :
2/3/4/6/8
Application Scope :
some light cargoes (>240kgs)
screen changer :
Automatic/handle
Thickness range :
0.4-1.2mm
Applicable raw materials :
100% recycled material
Melting point :
260 temperature
Keywords :
Strap Making Machine Production Line
Key Selling Points :
High Productivity
Winding :
Fully automatic/ semi automatic
Inverter :
IVNT
Motor :
GUGAO
Winder :
2/3/4/6/8 sets
Worn parts :
Provide some for free
Extruder :
Single screw extruder
Screen changer :
Automatic/ manual
Width :
5-19mm
Description

https://www.strap-makingmachine.com/videos-39626668-5-19mm-customized-polyethylene-pp-packing-belt-making-machine-with-plc-control-system-and-automatic-.html

5-19mm pp strap making machinery PP Strap Production Line with PLC Control


Process flow of PP strap making machine


① Feeding →② mixing material→③ pre-drying →④ melting and measuring extrusion →⑤ embryo (belt embryo) cooling and forming →⑥ oven pre-heating →⑦ primary stretching →⑧ secondary stretching →⑨ embossing → oven tempering and setting → cooling → finished product winding


Tips: if you have a choose of printing that you can printing first and then embossing in the project of eight.


Parameter of PP strap production line


Type

JTPP-90

JTPP-100

JTPP-110

JTPP-125

JTPP-135

JTPP-90/65

JTPP110/75

Strap of number

2

3

4

6

8

2

Sandwich belt

4

Sandwich belt

width

5-19mm

5-19mm

5-19mm

9-19mm

9-19mm

9-19mm

9-19mm

Thickness

0.4-1.2mm

Reducer mode

200

200

225

250

280

200/173

225/173

Screen changer

Automatic/ Manual

Production capacity

80-120kg/H

180-200kg/H

220-250kg/H

350-370kg/H

460-500kg/H

80-120kg/H

180-200kg/H

Screw type

Single screw

Double screw


Main features of PP belt making machine


1.PP belt making machine has high degree of automation, high output and low energy consumption;
2.PP belt making machine has simple operation and stable operation;
3.PP packaging belt produced by PP belt making machine has good straightness and uniform width and thickness control;
4.PP belt making machine can use new PP plastic or recycled PP plastic
5.PP belt making machine has long service life and stable operation.


Application of PP strap


1. Logistics and Warehousing Industry

2. Food and Beverage Industry

3. Building Materials Industry

4. Paper and Printing Industry

5. Retail and Supermarket Sector

6. Textile and Clothing Industry

7. Electronics and Appliance Industry

8. Agricultural Product Packaging


5-19mm pp strap making machinery PP Strap Production Line with PLC Control


FAQ


Q:What is the voltage of PP strap making equipment?
A:380V/50HZ, we support customization
Q:What is the length of the PP machine?
A: L:36 M.
Q:Where is the PP strap making machine produced?
A:We are from China.
Q:Can PP strap making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strap making machine stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strap production line support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
Q:What does the winding machine part of the PP strapping equipment look like?
A:Equipped with automatic winding machine/semi-automatic winding machine.
