Specifications
Brand Name :
JIATUO CHINA
Model Number :
JTPET-110
Certification :
ISO/ CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
20SETS/month
Delivery Time :
50-60DAYS
Packaging Details :
Plastic film
Plastic Processed :
PET
Screw diameter (mm) :
110mm
production capacity :
225-250kgs/H can be customized
Warranty :
1 years
Number of extruded strap :
3
Application Scope :
Brickyard, metal, steel, aluminum,brewery
screen changer :
double cylinder / single cylinder
Thickness range :
0.4-1.2mm
Width range :
9-32mm
Applicable raw materials :
bottle flake material, 100% broken material
Description

PET Packing Strapping Band Tape Belt Making Production Line With Synthetic Fiber Filter

The process fiow of PET strap making machine as below

Horizontal mixer→Crystallizing and drying system →filter materialExtruder→ Cooling Tank→pre-heating Oven→ first Stretching →second stretchingEmbossing machine →shaping oven→ cooling Haul-off machine →Winder

Parameters of PET strap production machine

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity PETJT90:200kg/h
PETJT100:250kg/h
PETJT125:350kg/h
4 Product size Width:9-32mm
Thickness:0.6-12mm
5 Installation power PETJT90:200KW
PETJT100:250KW
PETJT125:300KW
6 Cooling tower capacity 30T/H or 50T/H
7 Installation Dimensions PETJT90:45*2.0*7.0M
PETJT100:45*2.0*7.0M
PETJT125:60*3.0*8.0M

Features of JIATUO PET strap making machine


High Strength: PET strapping has extremely high tensile strength, typically reaching 50%–70% of that of steel strapping, allowing it to withstand heavy loads.

Good Flexibility: Compared to steel strapping, PET strapping is softer, less likely to scratch packaged goods, and safer to handle.

Corrosion Resistance: PET material is resistant to acids and alkalis, moisture-proof, and rust-proof, suitable for various environments.

Environmentally Friendly: PET strapping is recyclable, meeting environmental protection requirements.

Lightweight: Lightweight, easy to transport and handle, reducing logistics costs.

Impact Resistance: Possesses good impact resistance, suitable for long-distance transportation.


Application of PET strapping

PET strapping (also known as plastic steel strapping) is an ideal alternative to traditional steel strapping and PP strapping, thanks to its high strength, excellent toughness, corrosion resistance, and lightweight properties, as well as its eco-friendly advantage of recyclability. It is widely used in various scenarios such as industrial packaging and logistics bundling, with specific applications as follows:

  1. Building Materials Industry

    It is used for bundling heavy building materials like cement, gypsum boards, ceramic tiles, stone materials, aluminum profiles, and steel products. Its high tensile strength and breakage resistance can effectively prevent building materials from scattering and deforming during long-distance transportation. Unlike steel strapping, it will not rust and contaminate products.
  2. Metallurgy and Metal Processing Industry

    It is applied to bundle heavy metal products including steel pipes, steel plates, steel bars, and metal castings. PET strapping has better ductility and cushioning performance than steel strapping, which can avoid scratching the metal surface. Meanwhile, it can bear the weight of metal materials, meeting the stringent requirements of long-distance transportation by sea and land.
  3. Glass Industry

    It is used for bundling fragile items such as raw glass sheets and glass products. When matched with special packing buckles or hot-melt joints, it can realize firm and uniform stress bundling, reducing the breakage of glass caused by jolting and extrusion during handling and transportation, and improving packaging safety.
  4. Food and Beverage Industry

    It is suitable for unitized packaging of cartons, such as palletizing and bundling of whole cases of mineral water, beverages, beer, and dairy products, as well as bundling large packages of food like rice, flour, grain and oil. PET strapping is non-toxic and odorless, compliant with food contact safety standards. Moreover, it is moisture-proof and mildew-resistant, and will not contaminate food.
PET Packing Strapping Band Tape Belt Making Production Line With Synthetic Fiber Filter

FAQ

1. For PP(polypropylene) strapping band extrusion line
* What about the output of PP strapping band extrusion line? 120kg/hr, 260kg/hr, 380kg/hr.
* What about the size of strap that the PP strap machine can make? Width: 5-19mm; Thickness: 0.3-1.2mm;
* What about the installation power of the PP strap machine? 60kw/80kw/90kw/110kw;


2. For PET(polyester) strapping band extrusion line
* What about the output of PET strapping band extrusion line? 110kg/hr, 180kg/hr, 250kg/hr, 330kg/hr.
* What about the size of strap that the PET strap machine can make? Width: 9-32mm; Thickness: 0.4-1.2mm;
* What about the installation power of the PET strap machine? 150kw/200kw/250kw/300kw;
