PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line
Specifications
Brand Name :
JIATUO
Model Number :
PET-4
Certification :
CE, ISO
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
50 set/month
Delivery Time :
50~55 working days
Packaging Details :
plastic film or other standard package for sea shipping
Product type :
pet strap manufacturing machine
Raw material :
PET Flakes Or 100% Recycled Material
Capacity :
200-600 kg/h
PET Strap Width :
9-32mm
PET thickness Range :
0.4-1.2mm
Driven Type :
Electric
Voltage :
According To Customer's Factory
Product Color :
Green/Pink/yellow/black
Motor :
Siemens Motor
After-sales service provided :
Video technical support, Online support
Application :
Packaged Material
Warranty :
1 Year
Description

PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line

DESCRIPTION OF PET STRAP MANUFACTURING MACHINE

PET strap manufacturing machine

PET PP packing strap production is a new model of packing material machine, applying to advanced technology overseas. PET packing strap is the best replacement for old packing material, and is accepted in word packing industry. Nowdays, the PET PP packing strap hasebeen widly used in many industry such as paper steel, chemical fiber, cotton, printing wood and so on.

FEATURES:
Efficient production-----with high degree of automation and fast production speed.
High-quality products----The produced PET plastic steel belt has high strength, good toughness and strong tensile force.
Energy saving -----energy-saving design is adopted, the raw materials are mineral water bottles, which can be recycled and the manufacturing cost is low.
Easy operation----PLC automatic control, easy to operate.

PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line


EXTRUSION PARAMETERS TABLE

Model PET-2 PET-3 PET-4 PET-6 PET-8
Raw materials 100% Bottle flakes/crushed materials
Number of tapes 2 3 4 6 8
Width (mm) 9-32
Width (mm) 0.4-1.2
Maximum line speed(m/min) ≧150 ≧150 ≧150 ≧150 ≧150
PLC control system PLC PLC PLC PLC PLC
Screw Model 90 100 125 150 180
Reducer model 200 250 280 315 350
Dryer tank 3000L 4000L 5000L 6000L 6000L
Dehumidifier 1000 1000 2000 3000 3500
Metering Pumps 100CC 100CC 100CC 100CC 100CC
Screen Changer Single cylinder
Winding machine Automatic winding/ Semi-automatic winding
Production capacity /24 H 5-6T 7-8T 10-12T 12-15T 18-20T

PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line

PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line

APPLICATION INDUSTRY:


PET strap manufacturing machine is an industrial equipment used to make polyethylene terephthalate (PET) strapping, which is widely used for packaging and strapping in various industries such as logistics, construction, steel, aluminum, chemical fiber, cotton spinning, etc.

PET strap manufacturing machine 100CC metering pump PET plastic steel strap production line

FAQ

Q: What is the voltage of the PET strap manufacturing machine?

A: 380V/50HZ, three-phase (customization supported)

Q: What is the extrusion capacity of the PET strap manufacturing machine?

A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H

Q: What is the producible width of the PET strap manufacturing machine?

A: 9-32mm

Q: Can the PET strap manufacturing machine be customized?

A: Customization supported

Q: Where does the PET strap manufacturing machine come from?

A: China.

Q: What are the certifications for the PET strap manufacturing machine?

A: ISO CEO certification.

Q: What is the minimum order quantity for the PET strap manufacturing machine?

A: 1 set

Q: What is the weight of the PET strap manufacturing machine?

20T, 40GP container * 3PCS
