Specifications
Brand Name :
JIATUO CHINA
Model Number :
JTPP
Certification :
IS CEO
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
20 set/ month
Delivery Time :
30-40days
Packaging Details :
plastic film
Strap Width :
5-19mm
Extruder Power :
37KW
Video outgoing-inspection :
YES
Neat winding :
YES
Service guaranteed :
YES
production capacity :
300-600kg/h
First-class technology :
YES
Material :
PP Polypropylene New Material/recycled Material
Thickness :
0.6-1.2mm
operation mode :
PLC computer touch screen
length :
Negotiable
Paper tube size :
200*170/175/180mm
Description

PP packing strap making machine 5-15mm PP strapping equipment PP plastic strapping machine

PRODUCT DESCRITION OF PP STRAP MAKING MACHUNE:

pp strapping strap making machine

PP strap making machune/PP plastic strapping machine is a high-end plastic extrusion equipment used to produce a wide range of PP strapping products. Finished PP strapping can be produced in various colors including transparent, red, yellow, blue, white, and printed with lettering. Its applications are broad, primarily for: cardboard box strapping, appliance strapping, clothing strapping, fruit strapping, e-commerce product strapping, and building material strapping.

KEY HIGHLIGHTS:

Raw Materials-----100% virgin or recycled polypropylene.

Control Method----- PLC control system, configurable for different languages.

Motor----- This equipment uses a high-speed drive motor, ensuring stable and reliable performance with a low failure rate.

EXTRUSION PARAMETERS TABLE

Model PP-2 PP-4 PP-6 PP-8 PP-10 PP-12
Raw material PP polypropylene new material/recycled material
Number of tapes 2 4 6 8 10 12
Width(mm) 5-19 5-19 5-19 5-19 5-19 5-19
Thickness(mm) 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2 0.4-1.2
Line speed(m/min) ≧200-300 (Adjustable)
PLC control system PLC PLC PLC PLC PLC PLC
Screw Model 90 110 125 135 135 135
Reducer model 200 220 250 280 280 280
Winding machine Automatic winding machine /Semi-automatic winding machine
Screen Changer Automatic/Manua
Production capacity 24H 2.5-3T 6-7T 8-9T 10-11T 12-13T 13--14T

PP packing strap making machine 5-15mm PP strapping equipment PP plastic strapping machine

ENERGY-SAVING AND ENVIRONMENTALLY FRIENDLY:

Low consumables costs---- Compared to traditional manual strapping, this machine allows for precise control of strapping belt usage, reducing waste.

Low power consumption---- Energy-saving and environmentally friendly. Motor power typically ranges from 0.75-2.2kW, and energy-saving models feature variable frequency control.

Recyclable materials---- PP strapping belt is reusable, meeting environmental standards.

Low labor costs----- PLC automated program control eliminates the need for manual operation.

KDY MACHINE FEATURES:
Screen Changer — Features a large-area, four-screen rotary filtration system that allows for continuous, non-stop screen changing 24 hours a day, thereby minimizing manual intervention and boosting production capacity.
Main Extruder Die Head — Designed with a uniform extrusion flow channel, ensuring that the produced PP strapping bands maintain consistent specifications.

PP packing strap making machine 5-15mm PP strapping equipment PP plastic strapping machine

Process flow of PP packing belt production line

① Feeding →② stirring →③ pre-drying →④ melting and measuring extrusion →⑤ embryo (belt embryo) cooling and forming →⑥ oven preheating →⑦ primary stretching →⑧ secondary stretching →⑨ embossening → ⑩oven tempering and setting →⑪ cooling →⑫ finished product winding

Services :

Technical Support and Service for pp strapping strap making machine

We offer a wide range of technical support and services for our pp strapping strap making machine products, including:

  • Installation and commissioning of the extrusion line.
  • Operational and maintenance training.
  • Consultation and advice.
  • Technical support.
  • Spare parts supply.
  • Regular maintenance.
  • On-site repair and maintenance.
PP packing strap making machine 5-15mm PP strapping equipment PP plastic strapping machine

FAQ:

Q:What is the voltage of PP strapping equipment?
A:380V/50HZ, we support customization
Q:Can the PP strapping production equipment be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP strapping equipment produced?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
